8.XY
X and Y represent the 20th and 21st digits/letters of the digital barcode
respectively
9.XY
X and Y represent the 22nd and 23rd digits/letters of the digital barcode
respectively
The 12th-19th digits in the digital barcode are the company's internal fixed numbers, which
are not displayed in the window.
Read the nine groups of data and arrange them in order from left to right, skipping the
12th-19th digits, to get the barcode of the machine.
6.1.3 Factory reset
1) Before welding, press and hold the "Welding Mode Selection" key for 5 seconds to
reset factory settings.
2) After pressing and holding for 5 seconds, the display window will count down from 3. When
the countdown ends, the factory settings are reset. If the button is released before the
countdown ends, the factory reset will not take place.
3) The factory settings are as shown in the following table:
Item
Parameter Name
Reset Value
Remarks
Synergic MIG
parameters
Material & gas
Steel Ar80% CO
2
20%
Welding wire
diameter
θ0.8
Welding current
80 A
Welding arc length
0.0 V
MIG parameters
Welding speed
5m/min
Welding voltage
19.0V
General MIG
parameters
Burn back time
0.2S
Burn back voltage
13.0V
Welding torch
selection
Push torch
Operation method
2T
Inductance
0
Pre-flow time
0.1S
Post-flow time
0.5S
MMA parameters
Welding current
80A
Arc force current
40A
Hot start current
30A
Lift TIG parameters
Welding current
100A
Pre-flow time
0.5S
Post-flow time
5.0S
TIG downslope time
0.5S
