Page 64
I
U U
0
U
VRD
(LIft TIG mode)
NOTE! When starting the arc if the short-circuit time exceeds 2 seconds the welder
turns off the output current. Lift the welding torch clear of the work piece. Restart the
process as above (7.3.2) to start the arc again.
NOTE! During welding, if there is short circuit between tungsten electrode and the
work piece, the welder will immediately reduce the output current; if the short circuit
exceeds 1 second, the welder will turn off the output current. If this happens, the arc
will need to be restarted as above (7.3.2). and the welding torch needs to be lifted to
start the arc again.
7.3.4 Turn off the power supply after welding
(Same as section 7.1.7)
7.4. Standby
(Standby state interface in HD digital screen) (Standby state interface in LCD screen)
1) Enter standby state: In both MIG and Lift TIG modes, the machine will enter standby state
and close the display window in the operation panel if there are no welding or panel
