"Welding Voltage". For details about panel operations, see sections 7.12-7.14.
NOTE! If the digital torch is used, select the welding torch type of "Spool torch". The
parameters can be adjusted by both the adjustment knobs on the operation panel and
adjustment keys on the digital torch. During welding, the adjustment keys on the
digital torch cannot be used to adjust the parameters.
2) Spool torch
a. "Wire Feed Speed "adjustment potentiometer: Rotate the potentiometer clockwise to
increase the "Wire Feed Speed", and counterclockwise to decrease the speed.
(Select spool torch on HD digital screen) (Select spool torch on LCD screen)
The welding can only select spool torch in "Non-synergic" MIG mode.
3) Push-pull torch
4) a. "Wire Feed Speed "adjustment potentiometer: Rotate the potentiometer clockwise to increase the
"Wire Feed Speed", and counterclockwise to decrease the speed.
The push-pull torch cannot adjust the parameters.
a
