5.10. Adjustthenal-llsystem(optional)
5.10.1. Final-llsystemwithxeddisk(optional)
Adjust the nal-ll system before starting work with the machine.
Procedure:
1. Slide the plates with the grip supplied with the unit down to the pots
2. Turnthecrankhandletoadjusttheheightofthenal-llplate.Setthe
nal-llplatestojustabovethepots.
3. Adjustthesensoruntilthesoilonthenal-llplatesisattherequired
height.
4. Adjust the sensor at about 10 cm from the rim of the rotating disk.
5. Theproportionofthesoilfallingonthenal-llplatetothesoilfalling
directly in the pots can be adjusted in steps of 1/3.
6. Turn the machine on.
7. Setthesoildirectingchutessothatsufcientsoilfallsintothepotsand
ontothenal-lldiskbyadjustingtheleversonthesidesonthesoil
directing chutes.
5.10.2. Final-llsystemwithrotatingdisk(optional)
Adjust the nal-ll system before starting work with the machine.
Theproportionofthenal-llsoilsuppliedfromthenal-llplatetothesoiltothesoilsupplieddirectlytothepots
can be adjusted in steps of 1/3.
Procedure:
1. Slide the plates with the grip supplied with the unit down to the pots
2. Turnthecrankhandletoadjusttheheightofthenal-llplate.Setthe
nal-llplatestojustabovethepots.
3. Adjustthesensoruntilthesoilonthenal-llplatesisattherequired
height.
4. Adjust the sensor at about 10 cm from the rim of the rotating disk.
5. Turn the machine on.
6. Setthesoildirectingchutessothatsufcientsoilfallsintothepotsand
ontothenal-lldiskbyadjustingtheleversonthesidesonthesoil
directing chutes.
7. The speed of the rotating disk can be adjusted so that each operator
receives enough soil.
