Javo Plus M2.0 - Options; Operating Principle

User manual for Javo Plus M2.0
Version 22300779
page 8 / 27
3.3. Options
Thismachinemaybettedwithvariousoptionsasdeterminedbytheintensityofuseandcustomerrequirements.
Contact your Sales Consultant about these.
Options Code Specications
Cable,5x1.5,4meters,incl.16Aplug 900965
Continuous plug box 900966 Nonstandard
Height of pot track ex factory
Standard 805. Extra heights of 6 x 25
mm
Soil bin extension 223-180
1600 liters extra (1.6m³)
(1800x1660x600)
Pneumatic tires with triangle at back SU1ZL Wheels project outside the machine
Roller with motor 223-500-01-02 With frequency controller
Rotating brush before drill BM 223
Rotating brush after the drill BM 201
3.4. Operatingprinciple
Themachine'ssoilbinislledwithpottingsoil.Thesoilsupplybelttransportsthesoiltotheelevator.
The elevator collects the soil and pours it into pots that the pot dispenser places in the pot track's potholders. The
height and width of the pot track can be adjusted to cater for different pot sizes.
Thepottracktransportsthepotstothedrill,whichmakesholesinthesoil.Thedepthanddiameteroftheholes
made by the drill are adjustable. Once the holes have been made the pot track transports the pots to the take-off
unit that transfers them to a conveyor.
The machine is mounted on wheels for easy mobility.
3.5. Machineworkstations
Thismachinehastwoworkstations:atthepottrackandatthetake-offconveyor.
