Jaybeam Wireless 5157120 - Hardware for Mechanical Tilt on Wall Mounting (Three Mounting Points Version); Antennas with Two Mounting Pivot Points

Issue 05
Page
11/20
Installation Guide for 3G Antennas
2 pivots points antenna - Mechanical tilt kit - 0900184/00 or 0900188/00 part list
item description quantit
y
item description quantit
y
1 Long scissor arm 1 5 M8 x 130 mm hex head bolt 2
2 Short scissor arm 1 6 M8 plain washer 3
3 Spacing tube 1 7 M8 full nut 4
4 Tilt position label (top scissor only) 1
3 pivots points antenna - Mechanical tilt kit - 0900394/00 part list
item description quantit
y
item description quantit
y
1 Long scissor arm 2 5 M8 x 130 mm hex head bolt 4
2 Short scissor arm 2 6 M8 plain washer 5
3 Spacing tube 4 7 M8 full nut 8
4 Tilt position label (top scissor only) 1
2.5 - Hardware for mechanical tilt on wall mounting
2.5.1 - Antennas with two mounting pivot points
For such installation of a two mounting points antenna, both the panning accessory (see section 2.3) and
the mechanical tilt accessory (see section 2.4) need to be used together.
