Installation Guide for 3G Antennas
2 pivots points antenna - Pole mounting 115 to 150 mm - 0900182/00 part list
item description quantit
y
item description quantit
y
1 Pole clamp 4 6 M8 full nut 12
2 Antenna bracket 2 7 M8 x 130 mm hex head bolt 2
3 Spacing tube 2 8 M10 studding 260 mm 4
4 M8 x 30 mm hex head screw 4 9 M10 plain washer 8
5 M8 plain washer 6 10 M10 full nut 16
3 pivots points antenna - Pole mounting 115 to 150 mm - 0900501/00 part list
item description quantit
y
item description quantit
y
1 Pole clamp 6 6 M8 full nut 18
2 Antenna bracket 3 7 M8 x 130 mm hex head bolt 3
3 Spacing tube 3 8 M10 studding 260 mm 6
4 M8 x 30 mm hex head screw 6 9 M10 plain washer 12
5 M8 plain washer 9 10 M10 full nut 24
