C9 C17 C21 C29 C35 C37 C39 C42 C44
C46 C47 C19 C28
COND DISC 0.1 uF 50V +80-20% PRD249670-1040 13
C10 C12 C48 COND ELECT 1uF 50V 20% PRE039570-1090 3
C6 COND ELECT 2.2 uF 50V 20% PRE039570-2290 1
C24 COND ELECT 4.7 uF 50V 20% PRE039570-4790 1
C51 C52 COND ELECT 10 uF 50V 20% PRE039570-1000 2
C8 COND ELECT 100uF 50V 20% PRE039570-1010 1
C53 COND ELECT 220 uF 50V 20% PME039570-2210 1
q5 q6 XISTR NPN 2SC945P RAN200945-0001 2
C33 C34 C36 C40 C41 C43 C30 C45 C38
C31 C32
COND ELECT 330uF 25V 20% PRE039550-3310 11
C20 COND ELECT 470uF 16V 20% PRE039540-4710 1
R34 R35 RESISTOR 1.0 OHM 1/4W 5% CF QAF045000-1090 2
R4 R6 R23 RESISTOR 1.0K OHM 1/4W 5% CF QAF045000-1020 3
R1 RESISTOR 1.0M OHM 1/4W 5% CF QAF045000-1050 1
D22 D23 D20 D21 DIODE;RECTIFIER 1N4001 RAD114001-0010 4
D1 D2 D3 D4 DIODE 1N4007 RAD114007-0010 4
D6 DIODE SW; 1N4148 RAD114148-0010 1
R19 RESISTOR 4.7K OHM 1/4W 5% CF QAF045000-4720 1
ZD14 DIODE ZENR 5.6-5.9V 0.5W RAZ005006-0020 1
R33 RESISTOR 10 OHM 1/6W 5% CF QAF065000-1000 1
R16 R30 R31 R32 RESISTOR 10K OHM 1/6W 5% CF QAF065000-1030 4
R5 RESISTOR 22 OHM 1/6W 5% CF QAF065000-2200 1
R15 RESISTOR 24K OHM 1/6W 5% CF QAF065000-2430 1
R14 RESISTOR 33K OHM 1/6W 5% CF QAF065000-3330 1
R7 RESISTOR 68 OHM 1/4W 5P% CF QAF045000-6800 1
R18 RESISTOR 47K OHM 1/6W 5% CF QAF065000-4730 1
R10 RESISTOR 2.7K OHM 1/6W 5% CF QAF065000-2720 1
R9 RESISTOR 3K OHM 1/6W 5% CF QAF065000-3020 1
R17 R21 R22 RESISTOR 3K OHM 1/6W 5% CF QAF065000-3020 3
D7 D8 D9 D11 MBR 1100 1A 100V SHOTTKY BARRIER RAD101100-0010 4
D5 DIODE MUR160E 1A 800V RAD100160-0010 1
R8 RESISTOR 100 OHM 1/4W 5% CF QAF045000-1010 1
D13 DIODE ZENR 11.9-12.4V 0.5W RAZ005012-0010 1
JW3 JW4 JW5 JW6 WIRE BARE 22 GA TINNED XJP220000-0001 4
R3 RESISTOR 22K 2W 5% W/O KINK HI-AXIAL CF QHF205000-2230 1
D12 MBR1045 10A 45V MOT DRIVER W/KEY I/P FUN RHD101045-0010 1
FUSE CLIP DIA5xL20mm FUSE CFC011000-1001 2
TIN PLATE L26.5xW25xT0.8mm BRACKET GTP200002-0001 1
CONA 12P 200mm 2468#26 RAINBOW A=2.5 B=2512V VFLC01312-2000 1
L1 LINE FILTER 22mH D0.37x110TS JFT001003-0010 1
TR ER-29/32 230V 600uH PWR TRANS TSB023001-0010 1
L2 L3 L4 L5 COIL 3.3uH/3A VERTICAL PITCH 7mm SIL206001-3390 4
RV SURGE ABSORBER 10N471K RHU100471-2001 1
C7 CAP 0.01uF 1KV +80%-20% Y5 PLD3336Q0-1030 1
TIN PLATE BRACKET T=0.8mm GTP200003-0001 1
CONB CONNECTOR B4B-XH-A 4 PIN CCN250000-0104 1
C50 COND ELECT 220 uF 50V 20% PME039570-2210 1
RT NTC 5 OHM 5A DIA=13 mm RNT005130-5090 1
