WIRE 22 GA 80 mm RED 14-14 mm VWR0333GG-0080 1
WIRE 22 GA 90mm RED 4-4 VWR0333BB-0090 1
SCREW T3.0xL6xP1.06mm HSP140054-1060 4
C13 COND SAFTY 0.01uF 250V 20% PLY2705F0-1030 1
FU FUSE 3.15A 250V SLOW(WALTER TSD) KSA020315-0120 1
FUSE COVER;ID19.6xW11xH5.5mm UL DCR030001-0001 1
Head unit - mechanics parts
Installation Point
Description Material No. Qty.
IC5 IC7 IC8 IC6 HEAT SINK 10.5x15x24mm AL GAL100040-0002 4
FRONT PANEL HIPS BPF200002-0001 1
FUNCTION KEY ABS BPK202001-0001 1
POWER KEY ABS BPK212001-0001 1
VOLUME KNOB ABS BPK222001-0001 1
DVD DOOR HIPS PAINT PMS877C BPD200003-0001 1
DOOR LENS PMMA BPN200002-0001 1
WINDOW LENS PMMA BPN210002-0001 1
LOGO PLATE JBL ABS BPL200001-0001 1
DVD HOLDER HIPS BPD210003-0001 1
FRONT PANEL AL GAL200002-0001 1
BOTTOM CAB. SECC T=0.8mm GSE200003-0001 1
BACK PANEL SECC T=0.8mm GSE200004-0001 1
TOP COVER SECC T=0.6mm GSE200005-0001 1
TOP BRACKET SECC T=1.0mm GSE200006-0001 1
SCREW T3.0xL8xP1.06mm HSP140054-1080 8
SCREW M3.0xP0.5x8 HST143084-1080 3
SCREW T3.0x1.06PxL8mm HST140054-1080 11
SCREW M3.0xP0.5x6 HST143084-1060 13
BUSHING AC LINE BUSHING DBU001005-0010 1
WIRE TIE GT-90M 90mm DWT000001-0900 3
SPACER A=8.0mm B=1.3-1.7 PINGOOD SCB-8 DSS100022-0004 5
SPACER A=15.6 B=1.2-1.6 DSS100026-0001 2
SPONGE L100 x W8 x T1.5mm IVE200008-0001 1
SPONGE L10 X W10 X T13.5mm IVE200009-0001 1
RUBBER FOOT 19.5 x 2.5 MM BRF200004-0001 2
SCREW M3.0 X 0.5P TYPE TRIANGLE HSF143084-1080 6
LINE CORD 2P 1980mm BLK VDE W/3.96VH 4P VPE003252-0010 1
Mecha DVD LOADER DSL-710A DVS ATRAPI WVD100002-0006 1
Head unit - Tuner
Installation Point
Description Material No. Qty.
TUNER PCB ASSY APE200230-0001 1
CF103 CER FILTER 450 KHZ JFT005001-0030 1
CF101 CER FILTER 10.7 MHZ JFT005002-0020 1
CF102 CER FILTER 10.7 MHZ JFT005002-0040 1
XL152 CRYSTAL 4.5000 MHZ HC-49/U JQC013101-4550 1
TC001 COND TRIM 3 - 10 PF NP0 MVC001001-0010 1
TC002 COND TRIM 4.2 - 20 PF N450 MVC001002-0010 1
C166 COND ELECT 3.3 uF 16V 20% PVE939540-3390 1
C117 C171 COND ELECT 47 uF 16V 20% PVE939540-4700 2
