C014 COND POLY 560pF 50V 5% PVP026370-5610 1
VD001 VD002 DIODE TUNG AM TOSHIBA 1SV149B RHV100149-0001 2
L103 COIL 39 mH 10% D6xH11xP5mm SIL106003-3930 1
T102 AM IFT 455KHz Q=130 SIF010001-0040 1
T105 FM IFT 10.7MHz Q=60 MIN SIF020001-0050 1
T002 ANT OSC AM 4-6:10T 1-3:86T SIL013009-0011 1
T101 BIAS COIL 78 KHz SIL016001-0010 1
T103 T104 BIAS COIL 16 KHz SIL016001-0020 2
T003 OSC COIL 108uH (796 KHz) COIL SIL013010-0012 1
T001 OSC FM SUMIDA S-8N SIL013012-0010 1
SHLD CALBE 160mm BLACK 75 OHM VSW243BB2-0160 1
ANT JACK 2P+ANT PLUG BLK-BLK CJA005001-1010 1
C113 COND ELECT 47 uF 16V 20% PVE939540-4700 1
C107 COND ELECT 22 uF 16V 20% PVE939540-2200 1
EF001 TUNER PACK KWANGSUN KST-F404VA2 WTP000011-0001 1
XL151 CRYSTAL 4.332 MHZ HC-49/U JQC013101-4351 1
C104 C106 COND ELECT 33 uF 10V 20% PRE939530-3300 2
C109 C125 C126 C151 COND ELECT 10 uF 16V 20% PRE939540-1000 4
C012 C143 C163 C156 C157 COND ELECT 47 uF 16V 20% PRE939540-4700 5
C139 C140 COND ELECT 4.7 uF 16V 20% PRE939540-4790 2
C118 C123 C127 COND ELECT 1 uF 50V 20% PRE939570-1090 3
C124 COND ELECT 0.47 uF 50V 20% PRE939570-4780 1
C005 COND DISC 5 pF 50V +-0.25pF PRD113870-5090 1
C007 COND DISC 0.1 uF 50V +80-20% PRD339670-1040 1
C015 C101 C164 C167 COND DISC 0.022 uF 50V +80-20% PRD249670-2230 4
Q001 FET 2SK192A-Y/GR RAM200192-1001 1
Q104 Q105 XISTR NPN 2SC945P RAN200945-0001 2
Q101 Q102 XISTR NPN 2SC1675L NEC RAN201675-0001 2
Q103 XISTR PNP 2SA733Q,P NEC RAP200733-0001 1
R105 RESISTOR 100 OHM 1/6W 5% CF QAF065000-1010 1
R155 RESISTOR 1K OHM 1/6W 5% CF QAF065000-1020 1
R007 RESISTOR 100K OHM 1/6W 5% CF QAF065000-1040 1
R005 R104 RESISTOR 330 OHM 1/6W 5% CF QAF065000-3310 2
R110 RESISTOR 47 OHM 1/6W 5% CF QAF065000-4700 1
R123 RESISTOR 4.7K OHM 1/6W 5% CF QAF065000-4720 1
D001 D002 D003 D004 D101 DIODE SW; 1N4148 RAD114148-0010 5
L102 L104 L153 L154 L151 L152 CHOKE 10 uH 10% SAN001600-1000 6
J101 J102 J103 J104 WIRE BARE 22 GA TINNED XJP220000-0001 20
C165 CHIP CAP 1000 pF 50V 5% PYL410370-1020 1
C110 CHIP CAP 200 pF 50V 5% PYL410370-2010 1
C120 C154 C155 C173 C174 CHIP CAP 22 pF 50V 5% PYL410370-2200 5
C111 CHIP CAP 30 pF 50V 5% PYL410370-3000 1
C001 CHIP CAP 33 pF 50V 5% PYL410370-3300 1
C013 CHIP CAP 8 pF 50V 5% PYL410370-8090 1
C003 C009 C010 C105 C116 C122 C133 CHIP CAP 0.022 uF 50V 20% PYL439570-2230 13
C134 C144 C145 C169 C170 C011
C112 C114 C115 CHIP CAP 0.047 uF 50V 20% PYL439570-4730 3
C016 C006 C108 C161 CHIP CAP 0.1 uF 50V 10% PYL456470-1040 4
C135 C136 C119 CHIP CAP 1500 pF 50V 10% PYL456470-1520 3
