Q204 XISTR NPN 2SC945P RAN200945-0001 1
R225 RESISTOR 1K OHM 1/6W 5% CF QAF065000-1020 1
D201 D202 D203 D204 D208 DIODE SW; 1N4148 RAD114148-0010 5
R224 RESISTOR 68K OHM 1/6W 5% CF QAF065000-6830 1
R207 R211 R212 R213 R226 RESISTOR 100 OHM 1/6W 5% CF QAF065000-1010 5
R206 R208 RESISTOR 100K OHM 1/6W 5% CF QAF065000-1040 2
R209 RESISTOR 560 OHM 1/6W 5% CF QAF065000-5610 1
R230 R231 R201 R202 R203 R204 R20
R210 R215
RESISTOR 10K OHM 1/6W 5% CF QAF065000-1030 9
R219 RESISTOR 56K OHM 1/6W 5% CF QAF065000-5630 1
TA210 TA209 TA208 TA202 TA203 TA204
TA201 TA207
AI TACT SW SKHVBE3520 MAW060001-0010 8
R227 RESISTOR 2K OHM 1/6W 5% CF QAF065000-2020 1
JW201 JW202 JW203 JW204 JW205 JW206
JW207 JW208 JW209 JW210 JW211 JW212
JW213 JW214 JW215 JW216 JW217
WIRE BARE 22 GA TINNED XJP220000-0001 17
R233 RESISTOR 6.8 OHM 1/4W 5% CF QAF045000-6890 1
Q205 Q206 XISTR PNP 2SA733Q,P NEC RAP200733-0001 2
SPONGE L10 X W10 X T13.5mm IVE200009-0001 1
SN201 IRT SENSOR RPM6938-V4 RHO693804-2001 1
LCD FILTER L110xW27xT0.27mm PVC WHITE BFT211001-0001 1
LCD HOLDER ABS BPH200002-0001 1
LCD TOP ABS BPH210002-0001 1
COND FLAT CABLE 15P 250mm 2468#26 A=2mm VFLF01246-2500 1
D207 LED HI-BRIG 2x4.6mm BLUE KED600052-0010 1
POT2 R-ENCODER ;EC16B24204 ALPS MSW005007-0010 1
3P 190mm 2468#26 RAINBOW VFL301245-1900 1
CN2 CONNECTOR 4 PIN PITCH=2.0mm CCN200000-0104 1
IC202 IC 80 PIN PT6583 LCD DRIVER RCI006583-0001 1
IC201 DISPLAY IC DTE102251AIP KEYMOS KLD000052-0010 1
FILTER LENS PMMA BPN200003-0001 1
Head unit - Power board (power supply)
Installation Point
Description Material No. Qty.
POWER PCB ASSY APE200090-0001 1
IC7 IC 3 PIN 7812 12V 1A RHI007812-0001 1
IC6 IC 3 PIN 7912 RHI007912-0001 1
CN902 CN907 CONNECTOR 4 PIN P=3.96mm CCN396021-0104 2
IC2 IC 3 PIN TL431 RHI004310-0001 1
T901 PWR TRANS 230V 50Hz EI28 AXIAL TTA123011-0010 1
RL001 RELAY GJ-SH-112DM MRL012004-0011 1
PH IC 4 PIN PC817A RHI008170-0001 1
IC1 IC 8 PIN DIP NCP1002P DIP FOR CNTL RHI001002-0001 1
IC5 IC 3 PIN; LM317 POS ADJ REG. RHI003170-0001 1
C3 C4 C11 COND SAFTY 0.0022uF 400V 20% PVY1705K0-2222 3
C5 COND ELECT 68 uF 400V 20% PVE0395K0-6800 1
C54 COND SAFTY 0.01uF 250V 20% PVY2705F0-1031 1
C15 C18 COND ELECT 1000 uF 10V 20% PME039530-1020 2
Q3 Q4 XISTR NPN 2N3904 FAIRCHILD RAN203904-0001 2
C1 C2 COND SAFETY 0.22uF 275V X2P 20% PVX2705G0-2240 2
