FB103 FB104 FB105 FB106 FB107 FB201
FB202 FB203 FB204 FB205 FB206 FB207
FB208
CHIP BEAD 600 OHM AT 100MHz SCB008050-6010 13
C147 C148 C150 C151 CHIP CAP 470 pF 50V 5% PYL410370-4710 8
C152 C153 C154 C149
R4006 R4016 R4026 R4056 R4066 R4046 CHIP RES. 5.1K OHM 1/10W 5% QCF015020-5120 6
R4100 R470 R476 R482 R488 R494 CHIP RES. 1.5K OHM 1/10W 5% QCF015020-1520 6
IC120 IC 3 PIN IMP809 SOT23 RESETVOL 2.93V RCI000809-0003 1
R447 CHIP RES. 3K OHM 1/10W 5% QCF015020-3020 1
C466 C471 C476 C481 C486 CHIP CAP 330 pF 50V 5% PYL410370-3310 5
C166 C167 C171 C181 C186 C182 C177
C172 C176 C187
CHIP CAP 0.01 uF 50V 5% PYL456370-1030 10
IC121 IC 4 PIN B1117N-2.85 SOT-223 1A RCI011170-0001 1
R178 CHIP RES. 120 OHM 1/10W 5% QCF015020-1210 1
IC601 IC 25PIN BH7860FP VIDEO SIGNAL PROCESSOR RCI007860-0001 1
R4112 CHIP RES. 1.2K OHM 1/10W 5% QCF015020-1220 1
R415 R416 CHIP RES. 390 OHM 1/10W 5% QCF015020-3910 2
R180 CHIP RES. 3.9K OHM 1/10W 5% QCF015020-3920 1
L606 L604 INDUCTOR 2.7uH SAN201601-2790 2
R4230 RESISTOR 150 OHM 1/4W 5% CF QAF045000-1510 1
ZD405 DIODE ZENR 6.0-6.3V 0.5W RAZ005006-0030 1
R541 RESISTOR 39K OHM 1/6W 5% CF QAF065000-3930 1
EMCD01 DIODE 1N5392 1.5A 100V RAD115392-0010 1
C616 COND ELECT 22uF 50V 20% PRE039570-2200 1
C498 C499 C495 C496 C497 C494 COND ELECT 4.7 uF 50V 20% PRE039570-4790 6
EMC001 EMC004 EMC005 EMC010 COND DISC 0.1 uF 50V +80-20% PRD249670-1040 4
EMC006 EMC008 EMC007 EMC009 EMC102 COND DISC 0.001 uF 50V +80-20% PRD249670-1020 5
12P 200mm 2468#26 RAINBOW A=2.5 B=2512V VFLC01312-2000 1
CN401 D-SUB JACK 15P D-SUB 90* CGIC RC CJF015001-2002 1
WIRE 26 GA 90 mm BLACK 4-4 VWR0151BB-0090 1
COND DISC 0.1 uF 50V +80-20% PRD249670-1040 2
WIRE 26 GA 60 mm BLACK 4-4 VWR0151BB-0060 1
Head unit - Control board (Front board)
Installation Point
Description Material No. Qty.
CONTROL PCB ASSY APE200100-0001 1
XL201 CRYSTAL 4.5000 MHZ HC-49/S JQC023101-4550 1
CN203 CONNECTOR 3 PIN PITCH=2.0mm CCN200000-0103 1
IC201 IC 18 PIN CTM8B56EN(MCU1226) RHI008056-0001 1
C216 COND DISC 4700 pF 50V 10% PRD235470-4720 1
C201 COND ELECT 10uF 16V 20% PRE039540-1000 1
C208 C209 C210 C214 COND DISC 15 pF 50V 5% PRD113370-1500 4
C204 C205 COND DISC 22 pF 50V 5% PRD113370-2200 2
C220 C221 COND DISC 100 pF 50V 5% PRD113370-1010 2
C202 C206 C211 COND ELECT 100uF 16V 20% PRE039540-1010 3
C203 C207 C212 COND DISC 0.1 uF 50V +80-20% PRD249670-1040 3
C226 COND DISC 220 pF 50V 10% PRD235470-2210 1
C218 COND MULTI 0.33UF 10% 50V X7R PRL156470-3340 1
C215 COND DISC 820 pF 50V 10% PRD235470-8210 1
