THINER FLX UNION SOLTEK T22 XTN000022-0001 1
RL1 RL2 RL5 INDUCTOR 0.4uH 1 OHM 2W 5% SHN002501-4080 3
JP13 CON/WIRE 6P 100/80/120 1533#28 VWA020011-0001 1
JP7 CON/WIRE 2P 150mm 26AWG VFL21131B-1500 1
JP8 CON/WIRE 2P 500mm BLK VFL21131B-5000 1
C153 C253 C553 COND DISC 560 pF 50V 10% PRD235470-5610 3
C192 C292 C293 C592 C593 C193 COND DISC 0.1 uF 50V +80-20% PRD339670-1040 6
C151 C251 C31 C551 COND MYLAR 0.1 uF 100V 5% PRM0373A0-1040 4
QA01 QA02 XISTR NPN 2SC945P RAN200945-0001 2
Q4 XISTR NPN 2SC2001L NEC RAN202001-0001 1
Q5 Q6 XISTR NPN 2SC2878-A (TE2,.M) RAN202878-0001 2
Q3 XISTR PNP 2SA733Q,P NEC RAP200733-0001 1
CA02 COND ELECT 10uF 16V 20% PRE039540-1000 1
C1 C10 C11 C12 C2 C3 C4 C5 C6 C7 C8 C9 COND ELECT 100uF 25V 20% PRE039550-1010 12
C601 COND ELECT 47uF 25V 20% PRE039550-4700 1
C190 C191 C290 C590 C591 C291 COND ELECT 100uF 50V 20% PRE039570-1010 6
C101 C112 C201 C212
C301 C312 C401 C412 C501 C512
COND ELECT 1uF 50V 20% PRE039570-1090 10
C609 COND ELECT 2.2 uF 50V 20% PRE039570-2290 1
CA04 COND ELECT 4.7 uF 50V 20% PRE039570-4790 1
CA03 COND ELECT 10 uF 16V 20% PRE339540-1000 1
R155 R255 R555 RESISTOR 4.7 OHM 1/2W 5% CF QAF025000-4790 3
R1 R10 R11 R12 R2 R3 R4 R5 R6 R7 R8 R9 RESISTOR 100 OHM 1/6W 5% CF QAF065000-1010 12
R152 R154 R252 R254 R552 R554 RESISTOR 1K OHM 1/6W 5% CF QAF065000-1020 6
R151 R251 R551 RESISTOR 10K OHM 1/6W 5% CF QAF065000-1030 3
R33 RESISTOR 100K OHM 1/6W 5% CF QAF065000-1040 1
R153 R253 R553 RESISTOR 20K OHM 1/6W 5% CF QAF065000-2030 3
R34 RESISTOR 2.2K OHM 1/6W 5% CF QAF065000-2220 1
R35 RESISTOR 22K OHM 1/6W 5% CF QAF065000-2230 1
R30 R32 RESISTOR 270K OHM 1/6W 5% CF QAF065000-2740 2
R36 RESISTOR 470K OHM 1/6W 5% CF QAF065000-4740 1
R31 RESISTOR 5.6K OHM 1/6W 5% CF QAF065000-5620 1
D4 DIODE SW; 1N4148 RAD114148-0010 1
WIRE BARE 22 GA TINNED XJP220000-0001 57
C610 CHIP CAP 47 pF 50V 5% PYL410370-4700 1
C608 CHIP CAP 0.022 uF 50V 5% PYL456370-2230 1
R607 RA02 RA03 CHIP RES. 1K OHM 1/10W 5% QCF015020-1020 3
R100 R103 R200 R203 CHIP RES. 10K OHM 1/10W 5% QCF015020-1030 52
RA08 CHIP RES. 1M OHM 1/10W 5% QCF015020-1050 1
R102 R202 R302 R402 R502 CHIP RES. 5.6K OHM 1/10W 5% QCF015020-5620 5
RA05 CHIP RES. 2.2K OHM 1/10W 5% QCF015020-2220 1
R603 R604 R610 RA04 CHIP RES. 22K OHM 1/10W 5% QCF015020-2230 4
R101 R201 R301 R401 R501 R601 CHIP RES. 27K OHM 1/10W 5% QCF015020-2730 6
R611 CHIP RES. 36K OHM 1/10W 5% QCF015020-3630 1
RA01 R113 R213 R313 R413 R513 R612 CHIP RES. 3.9K OHM 1/10W 5% QCF015020-3920 7
RA10 CHIP RES. 470K OHM 1/10W 5% QCF015020-4740 1
RA07 CHIP RES. 56K OHM 1/10W 5% QCF015020-5630 1
R123 R122 R121 R120 CHIP RES. 6.8K OHM 1/10W 5% QCF015020-6820 29
R606 CHIP RES. 68K OHM 1/10W 5% QCF015020-6830 1
