JBL DSC 500 Service Manual

LED PCB ASSY APE200330-0001 1
CP2 CON/WIRE 4P 140mm UL2468#26 BLK A=2.0mm VFL41124B-1400 1
D211 D212 D213 D214 D215 D217 D218 CHIP LED WHITE SMD0805 KCD900805-0010 7
R235 R236 R237 R238 R239 R240 R241 CHIP RES. 75 OHM 1/10W 5% QCF015020-7500 7
SCREW STEEL SCREW M3xP0.5xL6mm FLAT HEAD HSF143084-1060 5
NUT M3.0xOD5.5xT2.5mm HNT130550-1230 1
Head unit - Packing
Installation Point
Description Material No. Qty.
POLY BAG L80xW220mm IVA000001-0019 1
POLY BAG L610xW540mm IVA000001-0061 1
SOLDER LUG/WIRE180mm UL1007#22 BLK CSL507035-0200 1
SPONGE L25xW15xT21mm FIREPROOF IVE110002-0001 1
SPONGE L10 X W10 X T13.5mm IVE200009-0001 1
SPONGE L20xW10xT0.5mm IVE100157-0001 2
SCREW M3x10x0.5P HST143084-1100 1
WASHER FIB OD8.0xID3.5xT1.0 mm HWF118035-6100 1
PLYFOAM BOTTON ITF200012-0001 1
PLYFOAM TOP ITF200013-0001 1
MASTER CARTON ICC200004-0001 1
OWNER'S MANUAL YOM200001-0001 1
Satellites speake
r
Installation Point Description Material No. Qty.
SATE. SPK ASSY JBL AFK200002-0001 1
SPK REAR ABS BLK BPA400004-0101 4
SPK FRONT ABS BLK BPF405003-0101 4
LOGO PLATE L12xW10xT2mm BPL400003-0102 4
RUBBER FOOT OD12.5xID6xT2.5mm BRF400005-0001 8
RUBBER FOOT OD12.5xID6.2xT6.8mm BRF400006-0001 4
SPK GRILLE L80xW100xT0.6mm GSP400002-0102 4
ACCOUSTIC L80xW80xT30mm FIBER W/UL IVM000002-0004 4
SPK DRIVER D22.4mm 30W TWEETER FSA243010-1801 4
SPK DRIVER 70x70mm 4OHM 30W FOR SATE. FSA213012-1401 4
PROTECT PCB ASSY FOR REAR/SATE. APE200040-0001 4
R1 RESISTOR#6 OHM 10W 5% HI QVEA05000-6090 4
R2 RESISTOR ESC360 QVE505000-1890 4
C1 COND ELECT 100 uF 50V 20% NON-POLAR PRE399570-1010 4
C2 COND ELEC 1.5uF 100V VON-POLAR 5% BP PRE3993A0-1590 4
RB3 SPK WIRE 100mm 2P 2468#22 RD-BLK VWS331000-0100 4
PTC1 PTC 0.5Ax60x050 MEXICO RPT005001-0020 4
RB1 CON/WIRE AY 2P 130mm 2468#20 RD-BK VWA350013-0001 4
RB2 TEM WIRE 130mm 2468#20 RD-BLK A+6.4/-3.7 VWT130431-0130 4
SCREW T3.0xL8xP1.06mm HSP140054-1080 8
SCREW T3.5xL8xP1.41mm HSF140074-3120 8
SCREW T3.5xP1.41x16mm HSP140071-3160 16
ACOUSTIC ABSORB L80xW80xT10 FIBER WHT IVM110001-0001 4
Center spaeke
r
Installation Point Description Material No. Qty.
CENTER SPK ASSY JBL AFK200003-0001 1
SPK REAR ;ABS BLK (JBL) BPA400007-0101 1
