Section 7: Reference
Balanced vs. Unbalanced Lines
Your EON 210P PA system can accept either type of input. There are two basic types of audio system
interconnections for audio signals: Balanced and Unbalanced.
Balanced Lines
In audio, a balanced line is a three-conductor system in which the two signal wires carry an equal, but opposite
voltage with respect to the ground wire. The ground wire acts only as a shield and does not carry any audio
VLJQDOFXUUHQW2XWVLGHLQWHUIHUHQFHVXFKDV5),5DGLR)UHTXHQF\,QWHUIHUHQFHLVHLWKHUVKLHOGHGIURPWKH
internal signal conductor, or if it gets into the cable is cancelled out by the opposite signals at the receiving end.
Balanced connections are preferred for long cable runs.
Unbalanced Lines
8QEDODQFHGFDEOHLVDWZRZLUHV\VWHPZKHUHWKHVKLHOGJURXQGZLUHDFWVDVRQHRIWKHFXUUHQWFDUU\LQJ
signal conductors. The center conductor enclosed by the shield is commonly known as the “hot” conductor.
Unbalanced audio cables do not reject noise as well as balanced lines. Unbalanced lines are typical in home
KL¿W\SHV\VWHPVDQGRQWKHRXWSXWVRIHOHFWURQLFPXVLFDOLQVWUXPHQWV7KHVHZRUNZHOOLIWKHGLVWDQFHEHWZHHQ
the components is short, the signal level is relatively high and all of the electronics used in the system are
plugged into the same AC service.
