21
Dolby Pro-Logic
Ò
A/V Receiver JSR-400
C66, 67, 82, 83, 1876-473-811 C-POLYESTER 100V 0.047uF ± 10% 9
94, 95, 125, 900,
908
C68 1862-330-804 C-ELEC/RA TAP 6*11 50V 33 UF ± 20% 1
C69, 709, 710 1862-010-804 C-ELEC/RA TAP 5*11 50V 1.0uF ± 20% 3
C70 1862-471-306 C-ELEC/RA TAP 8*12 10V 470uF ± 20% 1
C79, 87 1832-561-822 C-CERA/AX TAP 50V Y5P 560pF ± 10% 2
C80 1832-222-983 C-CERA/AX TAP 16V Y5R 1
0.0022uF ± 20%
C81, 84, 96, 97, 134 1876-104-811 C-POLYESTER 100V 0.1uF ± 10% 11
100, 102, 103,
105, 106, 117,
C86, 126 1832-562-983 C-CERA/AX TAP 16V Y5R 2
0.0056uF ± 20%
C89, 90 1832-330-772 C-CERA/AX TAP 50V SL 33pF ± 5% 2
C98, 99 1876-223-811 C-POLYESTER 100V 0.022uF ± 10% 2
C101, 104 1832-681-822 C-CERA/AX TAP 50V Y5P 680pF ± 10% 2
C110 1862-101-504 C-ELEC/RA TAP 5*11 16V 100uF ± 20% 1
C112 1876-332-811 C-POLYESTER/RA TAP 100V 1
0.0033uF ± 10%
C118, 119, 120, 121 1875-224-811 C-POLYESTER/RA STD 100V 4
0.22uF ± 10%
C124 1862-R68-804 C-ELEC/RA TAP 5*11 50V 0.68uF ± 20% 1
C129 1832-182-983 C-CERA/AX TAP 16V Y5R 1
0.0018uF ± 20%
C130 1862-221-305 C-ELEC/RA TAP 6*11 10V 220uF ± 20% 1
C142, 144 1862-R47-804 C-ELEC/RA TAP 5*11 50V 0.47uF ± 20% 2
C800, 801 1861-682-820 C-ELEC/RA 30*60 50V 6800uF ± 20% 2
C910, 911, 912, 1832-104-822 C-CERA/AX TAP 50V Y5V 6
0.1uF + 80%, -20%
913, 914, 915
C916 1832-472-983 C-CERA/AX TAP 16V Y5R 1
0.0047uF ± 10%
Integrated Circuits
IC1 1212-782-025 LC7821 FUNCTION SELECTOR 1
IC2, 3 1211-419-001 IC-SIP STK4192II HIGH POWER AMP 2
SANYO
IC4, 13 1212-455-001 IC-DIP NJM4558DD OP AMP JRC 2
IC5 1212-496-001 QUAD BILATERAL SWITCH 1
IC10 1212-110-001 IC-DIP NJW1102L D/S DECODER JRC 1
IC11 1212-970-001 IC-DIP NJU9702D D/S DELAY JRC 1
Diodes
D7, 21 1252-000-005J D-RECT TAP 100V 1A IN4002 M.D 2
D20 1253-000-010 D-BRIDGE 400V 6A KBU602 1
Miscellaneous
X1 1341-000-051 FIL-RESONATOR ZTA2.0MHZ CQ 1
L1, 2, 3, 4 1451-000-030 COIL-AF CHOKE 2UEW 0.9F 4
ID 10 0.7uH
JACK3 1514-000-020 JACK-RCA 1P JW-1512 BLK WAKA 1
JACK13, 14, 15 1514-000-021 JACK-RCA 4P JW-4104R JAEWON 3
SP3 1531-000-020 TERMINAL-PUSH 2P JW-5502A 1
JAEWON
SP 4 1531-000-021 TERMINAL-PUSH 8P JW-5508A 1
JAEWON
FU1 1541-5R0-001-1 FUSE 5 x 20mm 250V 5A UL 1
PO1 1782-000-001 R-POSISTOR P42T8D100B04 1
RY7 2022-000-001 RELAY DC24V 2CIP DG2SU DAI ICHI 1
WA1, 4 2111-023-005 CON-WAFER 5267-0 5A 5P P=2.5 2
MOLEX
WA2 2111-023-003 CON-WAFER 5267-03A 3P P=2.5 1
MOLEX
WA3 2111-021-014J CONNECTOR-WAFER 2253-14P-T 1
PLUG ILSAN
WA8 2111-026-003 CONNECTOR-WAFER 3P P=3.96 1
35313-0310 MOLEX
WA10 2111-023-009 CON-WAFER 5267-09A 9P P=2.5 1
MOLEX
WA11 2111-021-008 CONNECTOR-WAFER 2253-08P-T 1
PLUG ILSAN
WA12 2111-021-012 CONNECTOR-WAFER 2253-12P-T 1
PLUG ILSAN
CN2 2113-004-026 CONNECTOR-FFC:26P 1
008370-261-000-800 ELCO KOR
T1 2141-010-100 CONNECTOR-ASS’Y 1PM AWG22M 1
250MM UL1672
5241-000-090 HEAT-SINK AL RV-50 YONGBI 1
5541-001-010 WASHER SPRING ;NO 2 4
M3.0MC TOYO
5541-001-020 WASHER PLAT P/W 3.3*8.0*0.5 MC 4
TOYO
5636-130-080 SCREW-TAP BH 3*8.0 FZY 1
A123008000 TOYO
5636-140-030 SCREW A113016000 TOYO 4
5636-140-040 SCREW A183008000 TOYO 3
PCB ASSY A0112-002-151-3 MAIN PCB FULLY LOADED 1
ASS’Y PCB CONTROL JSR-400
Transistors
Q1 1243-319-001 TR-TAP TO-92 KTC3198(C1815)-GR 1
Diodes
D8, 10, 102, 1252-000-001 D-SI TAP IN4148(ISS131) 9
105-110
Resistors
R1 1742-102-721 R-CARBON TAP 1/8W 1KW± 5% 1
R2, 3, 4, 5, 22 1742-473-721 R-CARBON TAP 1/8W 47KW± 5% 5
R6, 9 1742-105-721 R-CARBON TAP 1/8W 1MW± 5% 2
R7 1744-4R7-731 R-CARBON TAP 1/4W 4.7W± 5% 1
R10 1744-100-731 R-CARBON TAP 1/4W 10W± 5% 1
R14, 15, 16 1742-103-721 R-CARBON TAP 1/8W 10KW± 5% 3
Ref # Part # Description Qty Ref # Part # Description Qty
