JBL JSR-400 - Page 26

22
Dolby Pro-Logic
Ò
A/V Receiver JSR-400
R18, 19, 20, 24, 25 1742-104-721 R-CARBON TAP 1/8W 100KW± 5% 5
R21 1744-221-731 R-CARBON TAP 1/4W 220W± 5% 1
R23 1742-221-721 R-CARBON TAP 1/8W 220W± 5% 1
Capacitor
C1 1862-R47-804 C-ELEC/RA TAP 5*11 50V 0.47uF ± 20% 1
C2 1862-470-404 C-ELEC/RA TAP 5*11 16V 47uF ± 20% 1
C4, 5 1862-R22-804 C-ELEC/RA TAP 5*11 50V 0.22uF ± 20% 2
C6, 7, 8 1832-331-822 C-CERA/AX TAP 50V Y5P 330pF ± 20% 3
C10 1832-223-001 C-CERA 25V Y5V 0.022uF +80%, -20% 1
C11 1881-000-010 C-GOLD 5.5V 0.047F SCDA5R5473V 1
SAMSUNG
C12, 22, 24, 25 1832-104-002 C-CERA/AX :TAP 50V Y5V 0.1uF 5
Rfre +80%, -20%
Integrated Circuits
IC1 1212-827-002 IC-DIP CXP82712-120S CPU SONY 1
Miscellaneous
RMC1 1264-000-021 SENSOR-REMOTE CRVIM352-B 1
38KHZ SAM YOUNG
LED 1 1271-000-019 LED RED 3 SLR34VT3 ROH 1
FLT 1 1277-000-010 FLT CM1558D RV-50 NORITAKE 1
X1 1341-000-080 FIL-RESONATOR ZTT10MHZ CQ 1
SW19 29-39 40-44 1671-000-013 SW-TACT KPT1105AM-1 4PIN 17
CN102 2113-004-026 CONNECTOR-FFC 26P 1
008370-261-000-800 ELCO KOR
CN101 2141-050-070 CNT-ASS’Y 5P 400MM WOOCHANG 1
BEOMHWAN
FLT 5441-000-120 CUSHION-FLT EVA BLK 5*25*120 1
RV-50
PCB ASSY A0112-001-191 CONTROL PCB FULLY LOADED 1
ASS’Y-PCB TUNER JSR-400
Transistors
Q101, 102 1243-319-008 TR-TAP TO-92 KTC3192-0 KEC 2
Q103, 302, 403 1244-101-010 TR-TAP TO-92M KRA101M KEC 3
Q201 1243-320-001 TR-TAP TO-92 KTC3200-GR KEC 1
Q202 1248-246-001 FET-TAP TO-92 2SK246-Y TOSHIBA 1
Q401, 402 1243-319-001 TR-TAP TO-92 KTC3198(C1815)-GR 2
Diodes
D302, 303, 402 1252-000-001 D-SI TAP IN4148( 1SS131) 3
ZD401 1254-5R6-009 D-ZENER TAP 0.5W 5.6V 1
MTZJ5.6B ROHM
Resistors
R14, 100, 412, 318 1744-101-731 R-CARBON TAP 1/4W 100W± 5% 4
R101, 418, 419 1742-101-721 R-CARBON TAP 1/8W 100W± 5% 3
R102 1742-122-721 R-CARBON TAP 1/8W 1.2KW± 5% 1
R103, 308 1742-222-721 R-CARBON TAP 1/8W 2.2KW± 5% 2
R104, 205, 206, 1742-331-721 R-CARBON TAP 1/8W 330W± 5% 5
333, 564
R105 1742-121-721 R-CARBON TAP 1/8W 120W± 5% 1
R106 1742-391-721 R-CARBON TAP 1/8W 390W± 5% 1
R107 1742-392-721 R-CARBON TAP 1/8W 3.9KW± 5% 1
R201, 304, 305, 1742-103-721 R-CARBON TAP 1/8W 10KW± 5% 5
444, 411
R202, 307, 401, 1742-102-721 R-CARBON TAP 1/8W 1KW± 5% 5
311, 317
R203, 316, 407, 408 1742-332-721 R-CARBON TAP 1/8W 3.3KW± 5% 4
R204, 207, 562 1742-221-721 R-CARBON TAP 1/8W 220W± 5% 3
R301, 302 1742-473-721 R-CARBON TAP 1/8W 47KW± 5% 2
R306 1742-153-721 R-CARBON TAP 1/8W 15KW± 5% 1
R312 1742-683-721 R-CARBON TAP 1/8W 68KW± 5% 1
R313 1742-560-721 R-CARBON TAP 1/8W 56W± 5% 1
R314 1742-223-721 R-CARBON TAP 1/8W 22KW± 5% 1
R315, 403, 404 1742-562-721 R-CARBON TAP 1/8W 5.6KW± 5% 3
R405, 406 1742-182-721 R-CARBON TAP 1/8W 1.8KW± 5% 2
R413, 416 1742-104-721 R-CARBON TAP 1/8W 100KW± 5% 2
R414, 415 1742-124-721 R-CARBON TAP 1/8W 120KW± 5% 2
R417 1744-221-731 R-CARBON TAP 1/4W 220W± 5% 1
R438 1742-393-721 R-CARBON TAP 1/8W 39KW± 5% 1
R441 1744-220-731 R-CARBON TAP 1/4W 22W± 5% 1
R556, 557, 558 1742-471-721 R-CARBON TAP 1/8W 470W± 5% 3
R565 1744-470-731 R-CARBON TAP 1/4W 47W± 5% 1
Capacitor
C21, 23, 404 1862-3R3-804 C-ELEC/RA TAP 5*11 50V 3.3uF ± 20% 3
C39 1832-103-483 C-CERA/AX TAP 16V Y5S 0.01uF ± 20% 1
C103, 317, 419, 1862-470-404 C-ELEC/RA TAP 5*11 16V 47uF ± 20% 5
421, 428
C104, 302, 303, 1832-223-001 C-CERA/AX TAP 25V Y5V 14
307, 308, 312, 0.022uF +80%, -20%
316, 416, 422,
434, 436, 437,
318, 450
C201 1876-102-811 C-POLYESTER 100V 0.001uF ± 10% 1
C202 1862-010-804 C-ELEC/RA TAP 5*11 50V 1.0uF ± 20% 1
C203, 204 1832-220-772 C-CERA/AX TAP 50V SL 22pF ± 5% 2
C306, 313, 401, 1862-100-504 C-ELEC/RA TAP 5*11 16V 10uF ± 20% 4
412
C314 1862-4R7-804 C-ELEC/RA TAP 5*11 50V 4.7uF ± 20% 1
C322 1875-154-811 C-POLYESTER STD 100V 0.15uF ± 10% 1
C323, 324 1832-473-001 C-CERA/AX TAP 25V Y5V 2
0.047uF + 80%, -20%
C402, 441 1862-R47-804 C-ELEC/RA TAP 5*11 50v 0.47uF ± 20% 2
C405, 417, 418, 1862-2R2-804 C-ELEC/RA TAP 5*11 50V 2.2uF ± 20% 5
430, 431
Ref # Part # Description Qty Ref # Part # Description Qty
