Dolby Pro-Logic
Ò
A/V Receiver JSR-400
Ref # Part # Description Qty Ref # Part # Description Qty
C413, 414 1832-681-822 C-CERA/AX TAP 50V Y5P 680pF ± 10% 2
C403 1876-473-811 C-POLYESTER/RA TAP 100V 1
0.047uF ± 10%
C438 1872-471-731 C-STYROL/TAP 50V 470pF ± 5% 1
C452 1832-104-822 C-CERA/AX TAP 50V 0.1uF ± 10% 1
Integrated Circuits
IC 2 1212-700-001 IC-DIP LM7001 PLL SANYO 1
IC 3 1212-126-001 IC-DIP LA1265 AM/FM IF SANYO 1
IC 4 1212-341-001 IC-DIP LA3410 FM MPX SANYO 1
Miscellaneous
VC1, 2 1252-000-040 D-VVC AM SVC321 SPA-D2 SANYO 2
PACK1 1291-000-011 TUNER PACK FM 87.5-108MHZ 1
KST-F701VA-3 KWANGSUNG
F101, 102 1321-000-0051 FILTER-CERAMIC 2
SFE10.7MA5-A(RED) CQ
F202 1321-000-0200 FILTER-CERAMIC :A450BL TOKO 1
F401 1341-000-0151 FIL-RESONATOR ZTB456F11CQ 1
F3 1341-000-060 FIL-RESONATOR LZU450C4N CQ 1
X2 1352-000-015J X-TAL HC-49/U 7.2MHZ 20PPM CQ 1
T4 1422-000-050 IFT-INSERT 7.5MM FD BLUE 1
KWANGSUNG
T2 1422-000-060 IFT-INSERT 7.5MM AA WHT 1
KWANGSUNG
T1 1432-000-040 COIL-INSERT 7.5MM AM ANT BLK 1
KWANGSUNG
T6 1432-000-050 COIL-INSERT 7.5MM AO RED 1
KWANGSUNG
L202 1444-3R3-002 INDUCTOR-AX TAP 3.3uH 1
TLAP02KR3R3K
ANT1 1531-000-003 TERMINAL-PUSH 4P JW-5504DB FCC 1
JAEWON
VR 301 302 1731-103-011 “VR-SEMI 6f , EVNDJAA0.3B14, 2
10K MASTSUSHITA”
VR 401 1731-224-002 VR-SEMI 6f EVNDJAA03BE5 1
220K 0hm MASTSUSHITA
CT1, 2 1815-020-001J C-TRIM 6f NPO 20pF CV05-C200-1 2
CHUNNIL
WA2 2111-023-002 CON-WAFER 5267-02A 2P P=2.5 1
MOLEX
WA5 2111-020-012 CONNECTOR-WAFER 2253-12S-T 1
SOCKET ILSAN
9961-000-001 PUSH TERMINAL EARTH PIN 1
ESD 1 2 D6854DMSA001 DIODE SCHOTTKY 2
PCB ASSY A0112-002-181-3 TUNER PCB FULLY LOADED 1
ASS’Y-PCB HEADPHONE JSR-400
Resistors
R52, 53 1771-681-752 R-METAL/AX FORMING 1W 680W± 5% 2
R82 1742-750-721 R-CARBON TAP 1/8W 75W± 5% 1
R83, 84 1742-331-721 R-CARBON TAP 1/8W 330W± 5% 2
Capacitor
C77, 81, 84 1832-104-002 C-CERA 50V Y5V 0.1uF +80%, -20% 3
C80 1862-330-504 C-ELEC 5*11 16V 33uF ± 20% 1
C82, 83 1832-101-822 C-CERA 50V Y5P 100pF ± 10% 2
Miscellaneous
JA1 1514-000-080 JACK-RCA 3P JW-3104D GOLD 1
Y/W/R JAEWON
JACK3 1515-000-011 JACK-H/P 6.3 ST HTJ-064-08D GOLD 1
CN5 2141-030-050 CNT-ASS’Y 3P 650MM WOOCHANG
BEOMHWAN
CN10 2141-050-040 CNT-ASS’Y 5P 650MM W00CHANG 1
BEOMHWAN
PCB ASSY A0112-001-1620 HEADPHONE PCB FULLY LOADED 1
ASS’Y PCB POWER SUPPLY JSR-400
Transistor
Q7 1243-319-001 TR-TAP TO-92 KTC3198 (C1815)-GR 1
Diodes
D11 1252-000-001 D-SI TAP IN4148 (ISS131) 1
DZ2 1254-012-033 D-ZENER TAP 0.5W 12V MTZJ12B 1
ROHM
DZ3 1254-5R1-021 D-ZENER TAP 0.5W 5.1V MTZJ5.1B 1
ROHM
Resistors
R38, 39, 46, 47, 81 1771-100-752 R-METAL/AX FORMING 1W 10W± 5% 5
R40, 44, 45 1744-102-731 R-CARBON TAP 1/4W 1KW± 5% 3
R41 1749-335-741 R-CARBON TAP 1/2W 3.3MW± 5% 1
R42 1744-331-731 R-CARBON TAP 1/4W 330W± 5% 1
R43 1744-104-731 R-CARBON TAP 1/4W 100KW± 5% 1
R80 1744-221-731 R-CARBON TAP 1/4W 220W± 5% 1
Capacitor
C25, 26, 41, 42, 79 1862-220-504 C-ELEC/RA TAP 5*11 16V 22uF ± 20% 5
C27, 28, 29 1862-470-705 C-ELEC/RA TAP 6*11 35V 47uF ± 20% 3
C31 1862-221-606 C-ELEC 8*11.5 25V 220uF ± 20% 1
C34 1832-104-822 C-CERA/AX TAP 50V 0.1uF ± 10% 1
C35 1825-000-010 C-DISC/AC AC250V 0.0047uF ± 20% 1
SEMKO UL/CSA
C36 1861-471-608 C-ELEC/RA 10*16 25V 470uF ± 20% 1
C39, 40 1861-222-610 C-ELEC/RA 16*25 25V 2200uF ± 20% 2
C78 1862-100-804 C-ELEC/RA TAP 5*11 50V 10uF ± 20% 1
C88 1825-104-000 C-AC 335M4104(0.1uF 275V) 1
SEMKO UL/CSA PILKOR
