24
Dolby Pro-Logic
Ò
A/V Receiver JSR-400
Ref # Part # Description Qty Ref # Part # Description Qty
Integrated Circuits
IC5, 9 1217-780-001 IC-TO220i +6V 1A 7806 REGULATOR 2
IC6 1217-781-001 IC-TO220i +15V 1A 7815 REGULATOR 1
IC7 1217-791-001 IC-TO220i -15V 1A 7915 REGULATOR 1
Diodes
D2-10, 17-20 1252-000-005J D-RECT TAP 100V 1A IN4002 13
DZ1 1254-027-001 D-ZENER TAP 1W UZP-27B 1
Miscellaneous
TRAN1 1411-000-020J TRANS-SUB EI -35X14 120/60 UL 1
FU1, 2 1541-1R6-013-1 FUSE 5 x 20mm T/L 250V 1.6A UL 2
FU3 1541-315-020-1 FUSE 5 x 20mm T/L 250V 315mA UL 1
FU4 1541-5R0-001-1 FUSE 5 x 20mm NM 250V 5A UL 1
FU1, 2, 3, 4 1551-000-010 HOLDER-FUSE 5 8
RY1 2022-000-010 RELAY DC12V ICIP DGIU DA11CH1 1
WA1 2111-023-005 CON-WAFER 5267-05A 5P P=2.5 1
MOLEX
WA2 2111-026-004 CONNECTOR-WAFER 4P P=3.96 1
35313-0410 MOLEX
WA3 2111-026-002 CONNECTOR-WAFER 2P P=7.92 1
35328-0210 MOLEX
WA4 2111-026-002J CONNECTOR-WAFER 2P P=7.92 1
JE202A-1T JAEEUN
WA5 2111-026-003 CONNECTOR-WAFER 3P P=3.96 1
35313-0310 MOLEX
CN11 2141-090-030 CNT-ASS’Y 9P 450MM P=2.5 1
WOOCHANG BEOMHWAN
5241-000-110 HEAT-SINK AL6063S-T5 W/PIN 3
L:40MM RV-50 YONGBI
5636-130-080 SCREW-TAP BH 3*8.0 FZY 3
A123008000 TOYO
PCB ASSY A0112-001-1616 POWER SUPPLY PCB FULLY LOADED 1
ASS’Y PCB TONE JSR-400
Resistors
R60, 63 1742-223-721 R-CARBON TAP 1/8W 22KW± 5% 2
R61, 62, 66, 67, 1742-104-721 R-CARBON TAP 1/8W 100KW± 5% 6
71, 75
R65, 68 1742-392-721 R-CARBON TAP 1/8W 3.9KW± 5% 2
R70, 73 1742-222-721 R-CARBON TAP 1/8W 2.2KW± 5% 2
R72, 74 1742-102-721 R-CARBON TAP 1/8W 1KW± 5% 2
R77, 79 1742-821-721 R-CARBON TAP 1/8W 820W± 5% 2
Capacitor
C47, 52 1876-153-811 C-POLYESTER 100V 0.015uF ± 10% 2
C48, 53 1876-823-811 C-POLYESTER 100V 0.082uF ± 10% 2
C49, 60 1832-680-772 C-CERA/AX TAP 50V SL 68pF ± 5% 2
C50, 55 1832-101-822 C-CERA/AX TAP 50V Y5P 100pF ± 10% 2
C51, 56, 59, 62 1862-4R7-804 C-ELEC 5*11 50V 4.7uF ± 20% 4
C54, 57 1862-220-504 C-ELEC 5*11 16V 22uF ± 20% 2
C58, 61 1876-332-811 C-POLYESTER 100V 0.0033uF ± 10% 2
C63, 64 1876-183-811 C-POLYESTER 100V 0.018uF ± 10% 2
Integrated Circuits
IC8 1212-455-001 IC-DIP NJM4558DD OP AMP JRC 1
Miscellaneous
CN6 2141-050-050 CNT-ASS’Y 5P SHIELD 200MM 1
WOOCHANG BEOMHWAN
CN7 2141-030-040 CNT-ASS’Y 3P 200MM WOOCHANG 1
BEOMHWAN
VR4 1721-104-030 VR-ROTARY 14MM, RK14K1280307 1
100K W , W/BUSH LG
VR2, 3 1721-104-040 VR-ROTARY 14MM 2
RK14K1280307100K W ALPS
5222-002-010 CASE-SHIELD SPTE 0.3t RV-50 1
PCB ASSY A0112-001-1618 TONE PCB FULLY LOADED 1
ASS’Y PCB VOLUME JSR-400
Resistors
R2 1744-4R7-731 R-CARBON TAP 1/4W 4.7W± 5% 1
R3 1742-103-721 R-CARBON TAP 1/8W 10KW± 5% 1
R4 1744-562-731 R-CARBON TAP 1/4W 5.6KW± 5% 1
R6, 7, 16, 17 1742-473-721 R-CARBON TAP 1/8W 47KW± 5% 4
R8, 9, 14, 15 1742-104-721 R-CARBON TAP 1/8W 100KW± 5% 4
R10, 11 1742-822-721 R-CARBON TAP 1/8W 8.2KW± 5% 2
R12, 13 1742-102-721 R-CARBON TAP 1/8W 1KW± 5% 2
R18, 19 1742-471-721 R-CARBON TAP 1/8W 470W± 5% 2
R51 1745-560-731 R-CARBON TAP 1/2W 56W± 5% 1
R54-59 1744-470-731 R-CARBON TAP 1/4W 47W± 5% 6
Capacitors
C1, 2 1862-101-304 C-ELEC/RA TAP 5*11 10V 100uF ± 20% 2
C3, 4, 11, 12, 43-46 1862-470-404 C-ELEC/RA TAP 5*11 16V 47uF ± 20% 8
C5-8, 13-16 1862-4R7-804 C-ELEC/RA TAP 5*11 50V 4.7uF ± 20% 8
C9, 10 1832-101-822 C-CERA/AX TAP 50V Y5P 100pF ± 5% 2
Miscellaneous
PCB ASSY A0112-001-1617 VOLUME PCB FULLY LOADED 1
ASS’Y-PCB VIDEO JSR-400
Transistors
Q2, 3 1243-319-001 TR-TAP TO-92 kTC3198 (C1815)-GR 2
Q4, 5 1244-126-001 TR-TAP TO-92 KTA1266(A1015)-Y KEC 2
Q6 1248-000-030 FET-TAP TO-92M 2SK117-GR KEC 1
Resistors
