Part Number Description Qty Reference Designator
Main Amp PCB
192-021tip35c transistor TIP35C NPN 1 Q107
192-022tip36c transistor TIP36C PNP 1 Q108
192-027c1815gr transistor 2SC1815GR NPN 2 Q101,115
192-201d882Y transistor KSD882Y PNP 1 Q117
192-202b772y transistor KSB772Y PNP 1 Q119
192-991d669a transistor HI-SINCERITY HSD669A NPN 1 Q106
192-992b649T transistor HSB649T PNP 1 Q105
197-00kb1405 diode 4A500V KBL405 BRIDGE 1 D110
197-101n4002 diode IN4002 1 D104
Miscellaneous
193-3m2520 insulator TO-3P 25x20mm 2 for Q107,108
162-10202001
wire 26AWC 1007 200mm RED
1
171-udhss124d relay 5A 24V UDH-SS124D 1 RY101
175-1c07v01 wire connector 7PIN PITCH=2.5mm 1 P101
175-1d02v01 wire connector 2PIN PITCH=3.96mm 1 P102
175-1d03v01 wire connector 3PIN PITCH=3.96mm 1 P103
323-AL-00020 Heat sink 65*32*31 1
351-AM03014A094 screw 1
352-AM03008D040 screw 4
361-FE-00051 transistor holder 1
361-NYL-00054 transistor sheet 2
Input/Preamp PCB
Resistors
110-12472j52
Resistor 4.7K 1/2W ±5% CF 52mm
2 R201,202
110-16102j26
Resistor 1K 1/6W ±5% CF 26mm
4 R213,214,215,254
110-16103j26 Resistor 10K 1/6W ±5% CF 26mm 14 R209,212,216,217,220,221,222,225,228,226,232,235,240,248
110-16104j26
Resistor 100K 1/6W ±5% CF 26mm
2 R231,266
110-16105j26
Resistor 1M 1/6W ±5% CF 26mm
1 R259
110-16122j26
Resistor 1.2K 1/6W ±5% CF 26mm
1 R264
110-16124j26
Resistor 120K 1/6W ±5% CF 26mm
1 R233
110-16151j26
Resistor 150Ω 1/6W ±5% CF 26mm
1 R253
110-16153j26
Resistor 15K 1/6W ±5% CF 26mm
1 R234
110-16154j26
Resistor 150K 1/6W ±5% CF 26mm
5 R203,204,205,206,252
110-16183j26 Resistor 18K 1/6W ±5% CF 26mm 2 R262,227
110-16205j26
Resistor 2M 1/6W ±5% CF 26mm
1 R257
110-16223j26
Resistor 22K 1/6W ±5% CF 26mm
4 R238,247,250,255
110-16273j26
Resistor 27K 1/6W ±5% CF 26mm
2 R223,237
110-16333j26
Resistor 33K 1/6W ±5% CF 26mm
1 R249
110-16472j26
Resistor 4.7K 1/6W ±5% CF 26mm
4 R200,207,258,260
110-16473j26
Resistor 47K 1/6W ±5% CF 26mm
2 R219,251
110-16512j26
Resistor 5.1K 1/6W ±5% CF 26mm
4 R210,211,229,230
110-16513j26
Resistor 51K 1/6W ±5% CF 26mm
1 R224
115-h503a104 Variable resistor D16 50K/1 A LEVEL
1
VR201
Capacitors
130-2b221k503 disc capacitor 220P 50V ± 10% 12 C204,205,207,208,210,211,212,214,220,230,200,249
130-2f104z503 disc capacitor 0.1U 50V +80/-20% 7 C232,242,244,245,246,252,254
130-sl470k503 disc capacitor 47P 50V ± 10% 1 C229
132-103j503
electolytic 0.01U 50V ± 5%
2 C223,224
132-104j503
electolytic 0.1U 50V ± 5%
3 C218,221,222
132-223ja03
electolytic 0.22uF 100V ± 5%
C215
132-473j503
electolytic 0.047U 50V ± 5%
2 C216,217
135-3105m50
electolytic 1U 50V ± 20%
1 C228
135-3106m50
electolytic 10uF 50V ± 20%
10 C201,202,206,213,219,231,241,243,251,253
135-3107m16
electolytic 100uF 16V ± 20% 2
C233,234
