Part Number Description Qty Reference Designator
Input/Preamp PCB
135-3226m50
electolytic 22U 50V ± 20% 1
C225
Semiconductors
192-027c1815gr transistor 2SC1815GR NPN 3 Q201,206,207
197-031n4148 diode 100mA 75V SIGNAL 1N4148 ROHM 11 D201,202,203,204,205,206,207,208,211,212,214
199-15000335 zener diode 3.3V 1/2W 52mm 1 D213
190-06m4558d I.C OPA 4558D DUAL OP-AMP
1
U203
190-16t1074cn I .C TL074cm QUAD OP-AMP
2
U201,202
195-10204hgw LED 204HGW 3c
1
D209
Miscellaneous
162-50159201 WIRE ASS'Y 2PIN 150mm
1
for D209
174-0rca326p JACK RCA-326 3 input
1
JK202
174-2psz406g1
JACK S-8071
1 JK203
174-2psz406g2
SPK JK 4PIN S-8072
1
JK203
Limiter PCB
110-16103j26
Resistor 10K 1/6W ±5% CF 26mm
8 R301,303,304,308,309,314,340,344
110-16183j26
Resistor 18K 1/6W ±5% CF 26mm
1 R302
110-16223j26 Resistor 22K 1/6W ±5% CF 26mm 2 R310,312
110-16273j26
Resistor 27K 1/6W ±5% CF 26mm
1 R341
110-16333j26
Resistor 33K 1/6W ±5% CF 26mm
1 R305
110-16472j26
Resistor 4.7K 1/6W ±5% CF 26mm
2 R342,343
110-16474j26
Resistor 470K 1/6W ±5% CF 26mm
1 R307
110-16751j26
Resistor 750Ω 1/6W ±5% CF 26mm
2 R311,313
110-16755j26
Resistor 7.5M 1/6W ±5% CF 26mm
1 R306
130-2f104z503 disc capacitor 0.1u 50V +80/-20% 2 C305,306
132-103j503
mylar capacitor 0.01U 50V ± 5%
2 C302,303
135-3226m50
electolytic 22U 50V ± 20%
2 C301,340
135-3476m25
electolytic 47U 25V ± 20%
1 C304
192-027c1815gr
transistor 2SC1815GR NPN
2 Q301,302
197-031n4148 diode 100mA 75V SIGNAL 1N4148 2 D301,302
162-50289001
wire CABLE ASS'Y280mm AWG26
1
175-9F40HR2
wire connector 40PIN PITCH=2.54mm HR2*40
0.15 P301
190-16tl074cn IC TL074CN ST 1 U301
MISCELLANEOUS
130-3f472md00
disc capacitor 4700p 400V ± 20%
1 On Power Switch
123-14j70d
Ferrite Core U-16.3*8.2*13
1
150-e8604107 Power Trans EI-86 60HZ 120V TT086996580 1 T1
152-u602015 LineCord SVT FT-2 6FT
1
154-u25006t0 Fuse 2.5A 250V 20mm
1
155-520020 Fuse Holder R3-11
1
162-10082007 WIRE RED 18AWG 80mm 8mm#1015
1
162-50652003
WIRE 650mm RED=205# 0.5T BLK=110# 0.5T
1
163-11009 wire tie 100mm
2
176-wjcel wire connector Pin CE-1
1
180-prf1003S
switch ROCK RF-1003-BB2-OHA 1
SW100
302-AL-00406-0VC Alu. Panel 1
306-ABS-00177 Rear cover 1
311-ABS-00028 Plastic knob 1
302-RUB-00033 Rubber cusion 4
323-AL-00141 Heat sink 1
333-EVA-00783 EVA (Gasket) 2
333-EVA-00807 EVA (Gasket) 2
333-EVA-00826 EVA (Gasket) 2
333-EVA-00835 EVA (Gasket) 2
335-NYL-00002 Cable ring 2
SUB200 (SCS200.7sys)
17
