jcb 3CX - Service Brakes Dismantling and Assembly

Dismantling and Assembly
The service brakes are located in the rear axle, as shown at
A. Instructions for dismantling and assembly of the brake are
described in Section F - Rear Axle Brakes.
40 - 1
Section G Brakes
9803/3280
Section G
40 - 1
Issue 1
Service Brakes
A264180
A
