Harness Interconnection
The harness number refers to and corresponds with the annotations in the schematic drawing on the adjacent page.
Harness No. Issue Remarks Page
1 Front Console
721/10940 1 4 speed Powershift / Synchro Shuttle 151 - 1
721/10937 3 6 speed Powershift (ShiftMaster) 151 - 3
2 Side Console
721/10936 1 Machines up to S/No. 933756 153 - 1
721/10970 2 Machines from S/No. 933757 153 - 5
3 Cab Roof
721/10966 1 USA only 155 - 1
721/10965 1 Not USA 155 - 3
4 Interior Light, Radio Speakers
721/11050 1 155-5
5 Steer Controls
721/10968 1 Not crab steer 157 - 1
721/10967 1 157-2
6 Cab Link
721/10943 1 6 speed Powershift (ShiftMaster) 160 - 1
721/10942 1 4 speed Powershift / Synchro Shuttle 160 - 3
7 Transmission
721/10941 1 6 speed Powershift 160 - 5
721/10938 2 Synchro Shuttle 160 - 7
721/10939 1 4 speed Powershift 160 - 8
8 Engine/Mainframe
721/10935 2 165-1
9 Rear Lights, Hydraclamp
721/10944 1 Sideshift 165 - 3
10 Rear Horn, Alarm
721/10946 1 Sideshift 165 - 4
721/10947 1 Centre mount 165 - 5
11 Auxiliary
721/10974 1 Excavator 165 - 6
*
150 - 1
Drawings
Introduction
The following drawings are reproduced from production electrical harness drawings. Each harness drawing includes tables
showing wire connections and destinations for all the connectors on the harness.
Section C Electrics
9803/3280
Section C
150 - 1
Issue 3*
Harness Data
