jcb JS130 User Manual

5 - 3
Section 1 General Information
9803/6410
Section 1
5 - 3
Issue 1
Service Tools (continued)
SECTION E - HYDRAULICS
Ram Piston Nut Removal/Fitting Rig
993/99525 Rig Assembly (not including spanners and
ram)
993/99522 Anchor Side Plate (supplied loose unwelded)
993/99523 Anchor Cross Member (supplied loose
unwelded)
993/99524 Ram Eye End Modification Plate Assembly
556/43400 Lift Ram
545/18000 Lynch Pin
811/50232 1,1/4” Pivot Pin
Ram Piston Nut Removal/Fitting Spanner
993/99512 Spanner 55 mm A/F
993/99513 Spanner 60 mm A/F
993/99514 Spanner 65 mm A/F
993/99515 Spanner 70 mm A/F
993/99516 Spanner 75 mm A/F
993/99517 Spanner 85 mm A/F
993/99518 Spanner 90 mm A/F
993/99519 Spanner 100 mm A/F
993/99520 Spanner 110 mm A/F
993/99521 Spanner 115 mm A/F
SSP0046 Spanner 80 mm A/F
SSP0047 Spanner 95 mm A/F
JS07050
