jcb JS130 - Page 362

Boom Ram - Replacement (cont’d)
6 Install the collar and then the bolt and nuts.
7 Connect the grease tube.
Note: Stroke the ram and release entrapped air. After
releasing the air, check for oil leakage.
74 - 5
Section E Hydraulics
9803/6410
Section E
74 - 5
Issue 1
Hydraulic Rams
