8 - 10
Inspection
All parts should be inspected for signs of wear or damage,
paying particular attention to the parts detailed below.
Section F Transmission
9803/6410
Section F
8 - 10
Issue 1
Traction Motor
Part
Rear flange 101
Spool 123
Shaft 102
Swash plate 103
Cylinder block 104
Piston 105
Shoe 106
Retainer plate 107
Thrust ball 108
Timing plate 109
Lining plate 115
Plate 116
Valve seat 118
Renew if these conditions exist
a Spool 123 bore is scratched.
b Valve 127 contact area is scratched.
c Depth to 127 contact area is large.
a Clearance to flange 101 bore exceeds 0.025 mm (0.001 in).
b Outer surface is scratched or unevenly worn.
a Oil seal 132 contact area is worn.
b Spline is worn.
a Evidence of thermal seizure.
a Spline is worn.
b Inner surface of bore excessively worn.
c Timing plate 109 sliding surface scratched or unevenly worn.
a Clearance between piston and shoe exceeds 0.15 mm (0.006 in)
b Shoe is abnormally or unevenly worn.
a Edge surface of inner circumference unevenly worn.
a Spherical retainer plate 107 sliding surface unevenly worn.
a Sliding surface is thermally seized and unevenly worn.
a Both edge surfaces unevenly worn.
b Thermal seizure is observed.
c Braking torque is less than the specified 255 Nm (188 lbf ft, 26 kgf m).
a Seat surface is scratched.
