8 - 11
Section F Transmission
9803/6410
Section F
8 - 11
Issue 1
Traction Motor
Inspection (cont’d)
Part
Valve 119
Bearings 149, 150
Relief valve body 212
Piston 213
Sleeve 202
Valve 201
Renew if these conditions exist
a Outer circumference surface is scratched.
b Seat surface is scratched.
a Pressure marks observed.
b Flaking is occurring.
c Unevenly worn.
a Piston 213 sliding surface is scratched.
a Clearance to body 212 exceeds 0.025 mm (0.001 in).
b Outer surface is scratched or unevenly worn.
a Seat surface is scratched.
a Sliding surface along sleeve 202 is abnormally worn.
b Clearance to sleeve 202 exceeds 0.020 mm (0.0008 in).
c Outer surface is scratched or unevenly worn.
