9 - 5
Section F Transmission
9803/6410
Section F
9 - 5
Issue 1
Reduction Gear - JS130
Inspection
Part
Spindle 2
Flange 3
Reamer bolt 19
†Gear A 4
†Gear B 5
†Crankshaft 9
†Bearing 22
†Bearing 23
Distance piece 10
Bearing 21
Renew if these conditions exist
a Excessive damage or wear.
a Gear teeth unevenly worn.
a Crankshaft does not rotate freely in the bearings.
a Sliding surface scratched or unevenly worn.
a Pressure marks present.
b Flaking surfaces.
c Unevenly worn.
†If any of these components show signs of the conditions listed, renew the complete gear assembly.
