CHAPTER 2 Operations and Maintenance
2 - 3
2-1 Outline of interface
The following interface are available in the EBA-3x series.
- ID-001 parallel interface (EBA-30/31 + Type A I/F conversion board)
- ID-003 JCM serial interface (EBA-30/31/32/33/34/35)
- ID-0D3 MDB interface (EBA-30/31/34/35)
- ID-0E3 ccTalk interface (EBA-32/33)
- ID-0F3 HII interface (EBA-32/33)
- ID-0** Other interface
2-2 ID-003 JCM serial interface
ID-003 is JCM bidirectional serial interface that enables acceptor status/operation control and
functional setup/verification by using polling (STATUS REQUEST) and commands (OPERATION
COMMAND and SETTING COMMAND) from the controller.
For communication specifications, refer to Chapter 3 "ID-003 Communication Specifications".
For denomination and vend code settings, refer to "ID-003 Data Setting Specifications of each
software".
2-3 ID-0D3 MDB interface
ID-0D3 is the MDB interface mainly used for vending machines.
2-4 ID-0E3 ccTalk serial interface
ID-0E3 is the serial interface provided by Money Control.
For communication specifications, refer to "Money Control: ccTalk Specifications".
2-5 ID-0F3 HII serial interface
ID-0F3 is the Host Intelligent Interface provided by Mars Electronics International (ID-0F3 interface
is to be supported).
2-6 Other interface
ID-001 JCM parallel interface is to be supported with the use of type A I/F conversion board.
2. Interface
