JCM EBA-34-SD3 - Disassembling F-Guide Unit

4 - 7
CHAPTER 4 Disassembly Instruction
4. Disassembling F-Guide Unit
4-1 Remove the cover from F-guide unit.
4-2 Remove the solenoid from F-guide unit.
4-3 Remove the board and the pulley from F-guide unit.
