CHAPTER 2 Operations and Maintenance
*1: When the bill validation result is "NG", the unit rejects the bill and accept it again, to try the
second validation.
*2: If the abnormal signal is output, remove the cause of error, and then turn on the power again,
or send a reset command from host controller.
*3: If the stacker-full signal is output, remove bills from the stacker box, and reposition the box.
The machine automatically starts initialization.
B
"Stack 2" command
received ?
Bill stacked
Bill transport
Operation stop
Stacker-full signal output
Stacker-full signal
detected ?
C
Vend signal output
No
Yes
No
Yes
*3
"Stack 1" command
received ?
Vend signal output
No
Yes
To Next Page
