JCM EBA-34-SD3 - Page 42

4 - 3
CHAPTER 4 Disassembly Instruction
1-3 Remove the rear cover from the stacker unit.
Thissidefirst
1-4 Remove stacker board at the left side of stacker
unit.
1-5 Remove gears from the stacker unit.
1-6 Remove screws of the right side from the stacker unit,
and then remove screws of the left side.
