JCM EBA-34-SD3 - Page 48

4 - 9
CHAPTER 4 Disassembly Instruction
5-4 Remove the gear-box from U-guide unit.
5-5 Remove the motor and the roller from the gear-box.
5-6 Remove the bracket from U-guide unit.
5-7 Remove the prism guide from U-guide unit.
