6 - 10
CHAPTER 6 Trouble Shooting
Check by Performance Test
7-5-10 "Stacker Sensor
Test".
Check by Performance Test
7-5-8 "Centering Mechanism
Test".
LD2 (Red LED) blinks 11 times.
[Connection failure between acceptor head
unit and stacker unit]
Check by Performance Test
7-5-10 "Stacker Sensor
Test".
Check whether the box key
is locked.
LD2 (red LED) blinks 15 times.
[The key of stacker unit is unlocked, on the
failure of stacker box key switch]
LD2 (Red LED) blinks 13 times.
[Centering mechanism failure]
Check by Performance Test
7-5-9 "Solenoid Test".
LD2 (Red LED) blinks 14 times.
[Failure of centering mechanism solenoid]
Check the connection
between acceptor head unit
and stacker unit.
LD2 (Red LED) blinks 16 times.
[ Acceptor head unit is detached from
stacker unit]
(locked)
To Next Page
