CHAPTER 1 Product Name & Specifications
7. Cabling
Mating connector
Housing
ZHR-7(JST)
Contact
SZH-002T-P0.5
Recommended wire
AWG26~28 UL1061
Acceptor's connector
Box type plug
XG4C-1634(OMRON)
Mating connector
Contact
MIL type socket
XG4M-1630-T(OMRON)
Recommended wire
27mm pitch flat cable
AWG28 UL2651
Contact
XG5M-1635-N(OMRON)
Recommended wire
AWG26~28 UL1007
Acceptor's connector
Pin header
S7B-ZR(JST)
