EBA
®
Series Banknote Acceptor (EBA-40) Integration Guide
Component Names
Figure 6 illustrates the EBA-40 component names and locations.
Figure 6 EBA-40 Component Names
a) Acceptor Unit
b) DIP Switch Block 2
c) DIP Switch Block 1
d) Coin Lock
e) Interface Connector
f) External Display Connector
g) SD3 Stacker Box
b
c
d
e
f
g
a
