JDE PROFESSIONAL CAFITESSE QUANTUM TOUCH - Technical Specifications; 4.1 Specifications

17
4- TECHNICAL SPECIFICATIONS
QUANTUM TOUCH
4- TECHNICAL SPECIFICATIONS
4.1 Specications
Facts Description
Weight
40 Kg (Empty)
50 Kg (Operational with lled water tank)
Cup Defaults for coee: S=100ml, M = 125ml, L = 180ml
Pot Defaults for coee: S=700ml, M = 900ml, L = 1200ml
Power supply 230V, 50/60Hz
Power consumption 3.15kW - 230V
Capacity
340 cups per hour (±43L per hour)
Power conguration: 230V 16A
Storage and operating
environment
Temperature: 5 - 32ºC
Humidity: 10% - 90%
Cooling compartment
Capacity: 2 x 2L/1.25L packs
Temperature : 2ºC – 5ºC
Boiler
Volume: 10L
Temperature: Adjustable from 60 – 96.5 ºC
Standard water connection
1/2” or 3/8” supply line with 3/4” BSP connection,
potable water supply line with stop valve.
Dynamic water pressure Min.: 0.08 MPa at 10L/min
Static water Pressure Max: 1.0 MPa
Refrigerant 0.016 kg of R600a
