Troubleshooting 37
T
ROUBLESHOOTING
Problem Probable cause(s) Suggested remedy
No fog output when the
machine is fired using
the Fog or Timer switch
Machine is not ready Allow time to reheat
Fluid is below min level Add fluid
Standby switch is OFF Set Standby to ON
Timer on-period (ton) is
set to 0 seconds
Set ton to at least 1
second
No fog output when
using DMX to fire the
machine
Incorrect DMX address Check settings
Machine is not ready Allow time with DMX on
No DMX termination Fit 120 Ohm resistor
Flu/Lo is displayed on
the Fog display
Fluid level is below
minimum
Add more fluid
Machine is not ready
after 20 minutes heating
time
Standby switch is OFF Set Standby to ON
Blown fuse on Power
control PCB
Disconnect supply and
replace fuse
Fog disperses too
quickly
Wrong grade of fluid
used for the application
Choose a longer lasting
fluid
Density level too low Increase density setting
(reduces fan speed)
Fuse blows repeatedly Electrical malfunction Refer to service
technician
