Jenny Science XENAX Xvi 48V8 User Manual

46
10.6.13 Input / Output
DESCRIPTION
Short
CMD
PARAMETER
Set type of PLC outputs (Source, Sink, Source/Sink)
-> refer chapter 5.4 Output Configuration
Set Output Type
SOT
0-65535
High / Low Activity of PLC outputs
-> refer chapter 5.4 Output Configuration
Set Output Activity
SOA
0-255
Set PLC output to logic 1 (level according SOT, SOA)
Set Output
SO
1-8
Equivalent to SO, but set all outputs binary coded
Bit 0 = Output 1, Bit 7 = Output 8
Set Output Hex
SOX
00-FF
Clear output (level according SOT, SOA)
Clear Output
CO
1-8
Status all Outputs,
0= logic 0, 1=logic 1
Tell Output
TO
Status all Outputs in HEX format
Tell Output HEX
TOX
Preload output number for output function assignment with
command TYOF
Number Output Function
NOF
1-8
Assign type of output function to the with NOF preloaded
output number (0 = no function, 1 = REF, 2 = INMO, 3 = EDPG,
4 = TGR, 5 = ERR, 6 = BRK, 7 = INPO, 8 = IFML, 9 = IFSE,
10 = INSE, 11 = INFO, 12 = WARN, 13 = INFM, 14 = STO1,
15 = STO2, 16 = SS11, 17 = SS12, 18 = SS21, 19 = SS22,
20 = SLS1, 21 = SLS2)
Type Output Function
TYOF
0-21
Trigger upward counting, absolute, at output #x defined in
Output-Function, pulse during 5ms
Trigger upward
TGU
± 2'000'000'000 Increment
Trigger downward counting, absolute, at output #x defined in
Output-Function, pulse during 5ms
Trigger downward
TGD
± 2'000'000'000 Increment
0=all Input HIGH active, 1= all Input LOW active,
2= individual input activity selection according to ILAS (value 0
and 1 puts ILAS to 0x000 respectively 0xFFF)
Input LOW active
ILA
0-2 / ?
individual input activity selection, 0=Input HIGH active,
1=Input LOW active
1. Hex for value binary inputs 9-12 only 0 or F, 2. And 3. Hex
value for input 1-8 (values 0x000 and 0xFFF put ILA to 0 resp. 1.
All other values are to 2 by ILA
Input Low Active Single
ILAS
0xx / Fxx / ?
Status all inputs, 0 = Low, 1 = High
/ ? incl. indication of input number
Tell Input
TI
1-12 / ?
Status single input, 0 = Low 1 = High
Tell Input
TI
1-12
Status all Inputs in HEX format
Tell Input HEX
TIX
Preload input number for input function assignment with
command TYIF
Number Input Function
NIF
1-8
Assign type of input function to the with NIF preloaded input
number (0 = no function, 1 = REF, 2 = IX, 3 = PG, 4 = SO, 5 = CO,
6 = JP, 7 = JN, 8 = CPOS, 9 = IP, 10 = SI, 11 = SIC, 12 = LS-,
13 = LS+,14 = EE, 15 = EE1, 16 = PWC, 17 = PRF, 18 = RSTO,
19 = OVRD, 20 = PGEX, 21 = DIF, 22 = PQ)
Type Input Function
TYIF
0-22
Parameter A of input function of with NIF preloaded input
number (value depending on input function, according to value
described in chapter 10.13.1 Selection of Input Functions)
Parameter A
PAIF
xx
Parameter B of input function of with NIF preloaded input
number (value depending on input function, according to value
described in chapter 10.13.1 Selection of Input Functions)
Parameter B
PBIF
yy
Shows present position captured with input
Tell Capture Position
TCP
1-8
Shows the position captured with input 12
Tell Capture Pos. Buffer
TCPB
1-8
