Jensen JMS2212 - Wiring; Wiring Diagram and Pinout

JMS2212
4
WIRING
TUNER/AMP MODULE
WIRED COMMANDER
EXTENSION CABLE
JMS2212
50Wx4
A
15 AMP ATO TYPE
FUSE WITH HOLDER
FRONT RCA LINE OUT
WHITE FEMALE
RCA CONNECTOR
FRONT RCA LINE OUT
RED FEMALE
RCA CONNECTOR
REAR RCA LINE OUT
WHITE FEMALE
RCA CONNECTOR
REAR RCA LINE OUT
RED FEMALE
RCA CONNECTOR
POWER/AUDIO
16-PIN FEMALE
CONNECTOR
AUX IN
WHITE FEMALE
RCA CONNECTOR
AUX IN
RED FEMALE
RCA CONNECTOR
USB 2.0
BROWN
WHITE
YELLOW
YELLOW
GRAY
WHITE
FEMALE ANTENNA
CONNECTOR
WIRED COMMANDER
4-PIN CONNECTOR
SIRIUS CONNECTOR
FEMALE 8-PIN
IPOD CONNECTOR
MALE 13-PIN
RIGHT REAR SPEAKER (+)
RIGHT FRONT SPEAKER (+)
LEFT FRONT SPEAKER (+)
LEFT REAR SPEAKER (+)
LEFT REAR SPEAKER (-)
LEFT FRONT SPEAKER (-)
RIGHT FRONT SPEAKER (-)
RIGHT REAR SPEAKER (-)
NO CONNECTION
NO CONNECTION
POWER ANTENNA
NO CONNECTION
GROUND
NO CONNECTION
+12VDC SWITCHED SOURCE
NO CONNECTION
