6
6.0 Specifications
Table 1
Model number 708580
Stock number
JBM-5
Motor and electricals
Motor type TEFC
Horsepower 1/2 HP (0.37 kW)
Motor Phase single
Motor Voltage 115V
Cycle 60 Hz
Listed FLA (full load amps) 6 A
On/off switch Toggle, with removable safety key
Motor speed 1750 RPM
Power transfer Direct drive
Power cord SJT 3x18AWG 300V, 6 ft. (183cm) with plug
Recommended circuit size
1
10 A
Capacities
Chuck capacity (i.e. maximum bit shank diameter) 3/8 in.
Chisel capacity 1/2 x 1/2 in.
Chisel shank capacity 5/8 and 3/4 in.
Head stroke 4-3/4 in. (121 mm)
Chisel center to fence maximum 3-3/16 in. (81 mm)
Capacity under hold down 4 in. (102 mm)
Dimensions
Fence size L x W 1-9/16 x 13-3/4 in. (40 x 350 mm)
Table size 13-1/2 x 6 in. (343 x 153 mm)
Base size 7-5/8 x 12-3/16 in. (199 x 310 mm)
Bushing sizes 5/8 and 3/4 in.
Overall height, assembled Maximum 30 in. (762mm) ; minimum 21 in. (534mm)
Main materials
Head and base Cast iron and steel
Table MDF
Column Steel
Weights
Net weight 44 lbs. (20 kg)
Shipping weight 51 lbs. (24 kg)
1
subject to local/national electrical codes.
L = length, W = width, H = height
The above specifications were current at the time this manual was published, but because of our policy of continuous
improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring
obligations.
