7
6.0 Specifications
Model number ..................................................................................................................................... JWBS-14SF
Stock number .............................................................................................................................................. 714500
Motor and electricals:
Motor type ....................................................................... totally enclosed fan cooled, induction, capacitor start
Horsepower ............................................................................................................................. 1.75 HP (1.3kW)
Phase ........................................................................................................................................................ single
Voltage ..................................................................................................................... 115/230V (prewired 115V)
Cycle .......................................................................................................................................................... 60Hz
Listed FLA (full load amps) ................................................................................................................... 15/7.5 A
Starting amps ......................................................................................................................................... 70/40 A
Running amps (no load) ....................................................................................................................... 4.0/2.0 A
Start capacitor ............................................................................................................... 400-480 MFD, 250VAC
Run capacitor ............................................................................................................................. 80μF, 450VAC
Power transfer ........................................................................................................................................... v-belt
On/off switch ................................................................................................................................... push button
Motor speed ...................................................................................................................................... 1720 RPM
Blade speed .................................................................................................................................... 3000 SFPM
Power cord length .................................................................................................................... 6-1/2 ft. (198cm)
Power plug installed ..................................................................................................................................... yes
Recommended circuit size
1
............................................................................... 30A (f or 115V); 20A (for 230V)
Sound emission......................................................................... 75 dB at 3ft (900mm) from blade, without load
1
subject to local/national electrical codes.
Capacities:
Maximum cutting height/resaw capacity ................................................................................. 13-1/2” (345mm)
Throat capacity........................................................................................................................ 13-1/2” (345mm)
Minimum blade width .................................................................................................................... 1/8” (3.2mm)
Maximum blade width .................................................................................................................... 3/4” (19mm)
Blade length .................................................................................................................. 125” (3175mm) +/- 1/2"
Blade provided ................................................................................................. hook type, 1/2” x 0.025” x 4 TPI
Wheel diameter ............................................................................................................................. 14” (356mm)
Materials:
Table ........................................................................................................................................ ground cast iron
Trunnion ..................................................................................................................................................... steel
Frame ......................................................................................................................................................... steel
Band wheels......................................................................................................................................... cast iron
Tires .............................................................................................................................................. polyurethane
Blade guides ................................................................................................................................... ball bearing
Resaw fence ....................................................................................................................... extruded aluminum
Paint finish.................................................................................................................................. powder coating
Table insert ......................................................................................................................... anodized aluminum
Door locking knobs.............................................................................................................. anodized aluminum
Table and Fence:
Table dimensions .....................................................................21-1/2”L x 16”W x 1-5/8”D (546 x 406 x 40mm)
Table tilt................................................................................................................................... 10° left, 45° right
Table height from floor at 90-degrees ........................................................................................... 39” (990mm)
Miter T-slot ......................................................................... 15/16”W x 3/8”D; opening 3/4"W (24 x 9.5; 19mm)
Resaw fence ...................................................................................................... 18-1/4”L x 6”H (463 x 152mm)
Dimensions
Base footprint .................................................................................................. 25”L x 17-3/4”W (635 x 450mm)
Overall dimensions of shipping carton ...............................29”L x 25-3/4”W x 79-1/8”H (735 x 655 x 2010mm)
Overall dimensions, fully assembled ..................................30”L x 26-1/4”W x 74-1/2”H (760 x 665 x 1890mm)
