Operation Manual
36
10. Remove the plunger and guide bushing (Fig-
ure 52) from the gland nut and inspect.
Note: The guide bushing may be stuck and
require some force to remove. Use a
tool in the cutout (Figure 53) to push
the bushing out. Use caution to avoid
damaging the gland nut.
Figure 52: Guide Bushing Removal (15K/20K Gland Nuts).
Guide
Bushing
O-Ring
Figure 53: Stuck Bushing.
Guide
Bushing
Cutout
