JETStream 3000 series - Page 56

Operation Manual
48
5. Press down on the valve spring retainer and
slide the spring keepers out from the assembly
(Figure 84).
6. Remove the valve spring and valve spring
retainer.
7. Remove the suction and discharge valves
(Figure 85).
8. Inspect the valves. Refer to “Valve Inspection”
on page 50 for inspection criteria.
Figure 84: Spring Retainer Removal.
Keeper
Spring
Spring
Retainer
Suction
Valve
Discharge
Valve
Figure 85: Valve Removal.
