Max CPU C-state
The optional settings: [Disabled]; [Enabled].
The optional items are: [C7]; [C6]; [C1].
SATA Configuration
Press [Enter] to make settings for the following sub-items:
SATA Controller(s)
The optional settings are: [Enabled]; [Disabled].
When set as [Enabled], user can make further settings in the ‘SATA Mode
Selection’ & ‘SATA Interface Speed’ items:
SATA Mode Selection
The default setting is: [AHCI].
SATA Interface Speed
The item is for user to set the maximum speed the SATA interface can support.
CHA A1 is always with Gen1 speed.
The optional settings are: [Gen1]; [Gen2];[Gen3].
SATA Port
Port
The optional settings: [Disabled]; [Enabled].
M.2 SATA
Port
The optional settings: [Disabled]; [Enabled].
Network Stack Configuration
Press [Enter] to go to ‘Network Stack’ screen to make further settings.
Network Stack
Use this item to enable or disable UEFI Network Stack.
The optional settings are: [Enabled]; [Disabled].
When set as [Enabled], the following sub-items shall appear:
Ipv4 PXE Support
The optional settings are: [Disabled]; [Enabled].
Use this item to enable Ipv4 PXE Boot Support. When set as [Disabled], Ipv4 boot
