Section 9—Specifications
9-10 31211031
Dimensions
Note: Values will vary depending on machine configuration.
Maximum Overall Height
642 ..................................................................................................................................96 in (2438 mm)
943 ..................................................................................................................................98 in (2489 mm)
1043................................................................................................................................99 in (2513 mm)
1055, 1255..................................................................................................................100 in (2540 mm)
Maximum Overall Width
642, 943
No Outriggers .....................................................................................................97 in (2470 mm)
With Outriggers
Outriggers Engaged................................................................................134 in (3404 mm)
Outriggers Not Engaged .........................................................................97 in (2470 mm)
1043
Outriggers Engaged .......................................................................................134 in (3404 mm)
Outriggers Not Engaged.................................................................................97 in (2470 mm)
1055, 1255
Outriggers Engaged .................................................................................126.25 in (3207 mm)
Outriggers Not Engaged.........................................................................100.75 in (2559 mm)
Maximum Track Width .............................................................................................. 84.25 in (2140 mm)
Wheelbase
642, 943, 1043...........................................................................................................135 in (3430 mm)
1055, 1255.............................................................................................................. 137.5 in (3493 mm)
Length at Front Wheels
642 ........................................................................................................... Not Available at Publication
943 ........................................................................................................... Not Available at Publication
1043......................................................................................................... Not Available at Publication
1055, 1255.............................................................................................................. 200.2 in (5086 mm)
Overall Length (no forks)
642 ................................................................................................................................227 in (5774 mm)
943, 1043 ....................................................................................................................236 in (6001 mm)
1055, 1255..................................................................................................................243 in (6168 mm)
Ground Clearance
642, 943........................................................................................................................... 17 in (432 mm)
1043.................................................................................................................................. 18 in (447 mm)
1055, 1255...................................................................................................................... 18 in (457 mm)
Turning Radius Over Tires
642 ........................................................................................................... Not Available at Publication
943 ........................................................................................................... Not Available at Publication
1043......................................................................................................... Not Available at Publication
1055, 1255..................................................................................................................337 in (8560 mm)
