Dry protection and Overflow protection common
pin,
6.6.2 Water level sensor connection
Two kinds of water level sensor you can select as shown below:
Sensor A Sensor B
Figure6-6 Water level sensor
Notice
！
If you select overflow protection water level sensor, you need to set the value
of “OF-F”, the LCD menu ”Settings” "Para Set" "OF-F" to modify
to “ON”. The setting method with reference to“
8.3.4.3 Key Parameters of
the System Set
”.
If you selected water level sensor A, then water sensor installation method is
shown below:
