Jntech JNP22KH-V5 - Motor Parameters Detection and Commissioning; Motor Parameters Detection

52
JNP30KH
380V
57A
30KW
50Hz
1475
2875
0.86
---
---
60Hz
1770
3450
JNP37KH
380V
71A
37KW
50Hz
1475
2875
0.86
---
---
60Hz
1770
3450
JNP45KH
380V
85A
45KW
50Hz
1475
2875
0.86
---
---
60Hz
1770
3450
JNP55KH
380V
104A
55KW
50Hz
1475
2875
0.86
---
---
60Hz
1770
3450
7.4 Motor parameters’ detection and commissioning
7.4.1 Motor parameters’ detection
7.4.1.1 Motor parameters’ detection
After modifying the motor parameters, press "ENTER" and "DOWN" at the same time to
return to the main interface of the priority screen, and then long press "ON/OFF" key 4S,
the inverter starts to test the motor parameters. If the test is completed correctly, it will
prompt "Test is completed, whether to start up"; If the detection fails, the inverter will
prompt "stator detection fails". In this case, it is necessary to refer to "Fault 200~ Fault
203" in "9.1 Troubleshooting" to find the cause.
