1.2 Instructions for Related Displayed Symbols
No. Symbols Instructions
1
Up and down louver (swing) function
2
Left and right louver (swing) function
3
This row left intentionally blank.
4 Sleep function
5 Auto mode
6 Cooling mode
7 Dry mode
8 Fan mode
9 Heating mode
10
This row left intentionally blank.
11 I-Demand function
12 Absence function
13
Shielding status (Buttons, temperature, ON/OFF, mode or energy saving
is shielded by remote monitor)
14 Current set fan speed
15 Memory function (Memory in power failure)
16 Save function
17 X-fan function
