Johnson Controls DWCR2 - Function Instructions of Buttons; 3 Operation Instructions; Menu Structure

Wired Controller DWCR2
4
2.2 Function Instructions of Buttons
No. Button name Button Function
1 FAN
Set low speed, low-medium speed, medium speed, medium-high
speed, high speed, turbo and auto speed.
2 ∧
(1) Set temperature
(2) Set parameter
(3) Move option cursor
6 ∨
3 ON/OFF/BACK
(1) Turn on or turn off unit
(2) Return to last page
4
LOUVER Set up&down louver (swing) and set left&right louver (swing)
5 ＜
(1) Set related function on or off
(2) Move option cursor
(3) Set parameter
8 ＞
7 MENU/OK
(1) Enter menu page
(2) Confirm setting
9 MODE Set auto, cooling, dry, fan and heating modes for indoor unit.
3 Operation Instructions
3.1 Menu Structure
Normal setting of wired controller can be set directly on the main page, including
fan speed, louver (swing), set temperature, mode, ON/OFF. The setting and
status view of other functions
can be set in corresponding submenu. Detailed menu
structure is shown in Fig. 3.
